Mitsubishi Outlander XL. Manual - part 1274
REAR AXLE FWD
M22700000020USA0000010000
The rear axle has the following features:
｠
The wheel bearing is a unit ball bearing (double-row
angular contact ball bearing) which incorporates the
oil seals and is highly resistant to thrust loads.
｠
The number of parts has been reduced by
integrating the magnetic encoder for ABS wheel
speed detection into the wheel bearing.
SPECIFICATIONS
Item
Specification
Wheel bearing
Type
Unit ball bearing (double-row angular
contact ball bearing)
CONSTRUCTION DIAGRAM
ZC5017810000
Rear hub
Oil seal
Ball bearing
Magnetic
encoder
REAR AXLE AWD
M22700000030USA0000010000
For the rear axle, the unit bearing (double-row angular
contact ball bearing) in which the hub and ball bearing
are incorporated has been adopted for the wheel
bearing, and the EUJ-ETJ type constant velocity joint
for the driveshaft.
The following features are also available.
｠
The lightweight and compact EUJ type constant
velocity joint has been installed on the wheel side
of the driveshaft, and the lightweight compact ETJ
type constant velocity joint has been installed on the
differential side.
｠
Adoption of the electronic control AWD optimizes
the size of the driveshaft constant velocity joint and
reduces weight.
｠
Lead-free grease for the constant velocity joint has
been adopted.
｠
Hexavalent chromium has been eliminated from the
dust cover material.
27-2
REAR AXLE
REAR AXLE FWD
