OTHER DEVICES

M17001000056USA0000010000

ZC603703

A/C compressor

0000

A/C refrigerant
temperature switch

COMPONENT LOCATIONS

70-23

OTHER DEVICES

MEMO

70-24

COMPONENT LOCATIONS

GROUP 80B

SPLICE LOCATIONS

CONTENTS

HOW TO READ SPLICE LOCATIONS
...............................

80B-2

INDEX..........................

80B-3

ENGINE COMPARTMENT.............

80B-5

ENGINE AND TRANSAXLE...........

80B-5

DASH PANEL.....................

80B-6

FLOOR AND ROOF.................

80B-7

DOOR...........................

80B-8

LIFTGATE.......................

80B-8

80B-1

HOW TO READ SPLICE LOCATIONS

M18002000001USA0000010000

"Splice  locations"  describes  splice  points  of  each
wiring harness on an actual vehicle. Some variations

are included in one splice location. Accordingly, some
locations may not be applicable for individual vehicles.

ZC6005920000

Indicates a splice point number.
The splice point numbers are identical to those in "CIRCUIT DIAGRAMS," making them easy to use.
In addition, the splice point numbers are usually numbered clockwise.

         Example: S 013







  Sequential number







  Prefix meaning splice point

S013
S014

S015

S016

S033

S032

S031

80B-2

SPLICE LOCATIONS

HOW TO READ SPLICE LOCATIONS
