Mitsubishi Outlander XL. Manual - part 1216





ZC6010350001

A

Fan control relay

Condenser fan relay

Radiator fan relay

Headlight relay (high)

Headlight relay (low)

Starter relay

A/T control relay

Theft-alarm horn relay

ZC601149

B

Heated seat relay

Rear window defogger
relay

ETACS-ECU

Blower relay

0000

ZC6034880001

Selector lever
assembly

C

Shift lock
control relay

CONTROL UNIT

M17001000007USA0000010000

Name

Symbol

Name

Symbol

A/C-ECU

M

Headlight automatic leveling-ECU

N

ABS-ECU

A

KOS-ECU

J

Audio visual navigation unit

F

Occupant classification-ECU

P

AWD-ECU

H

Power

 window

 main

 switch

(incorporating CPU)

Q

CAN box unit

F

Column  switch  (incorporating  column-
ECU)

D

Receiver  antenna  module  <vehicles
with KOS>

I

Combination meter (incorporating CPU) E

SRS-ECU

K

Engine control module

B

Sunroof

 assembly

 (incorporating

sunroof-ECU)

O

ETACS-ECU

G

Hands free module

L

Transmission control module

H

COMPONENT LOCATIONS

70-3

CONTROL UNIT

Name

Symbol

Name

Symbol

Headlight

 assembly

 (incorporating

discharge-ECU)

C

Wireless  control  module  <vehicles
without KOS>

I

ZC601643

A

B

C

D

E

F

G

H

I

J

K

L

N

M

0002

*

ZC6033350000

P

O

Q

NOTE:

The * symbols indicate equipment at both

sides.

ZC6010550000

A

ABS-ECU

ZC6010310000

Engine
control
module

B



70-4

COMPONENT LOCATIONS

CONTROL UNIT

ZC6013530000

Headlight assembly
(incorporating discharge-ECU)

C

ZC6013590000

Column switch
(incorporating
column-ECU)

D



ZC6010380000

Combination meter
(incorporating CPU)

E

ZC6013570000

Audio visual
navigation unit

F

CAN box unit



ZC6011480000

ETACS-ECU

G

ZC6010510000

Transmission
control module

H

AWD-ECU

ETACS-ECU



ZC6011630000

I

Ignition switch

Wireless control module
<vehicles without KOS>
receiver antenna module
<vehicles with KOS>



COMPONENT LOCATIONS

70-5

CONTROL UNIT

ZC6011620000

KOS-ECU

J

Steering
shaft

ZC6033340000

SRS-ECU

K



ZC6013600000

Hands free
module

L

ZC6010530000

A/C-ECU

M

Heater unit assembly



ZC6010520000

Headlight automatic
leveling-ECU

N

ZC6033330000

Sunroof assembly
(incorporating sunroof-ECU)

O



ZC6016320000

Occupant
classification-ECU

Front passenger’s seat

P

ZC6010290000

Power window main switch
(incorporating CPU)

Q

70-6

COMPONENT LOCATIONS

SENSOR
