STEP 3. Measure at the lower metal part of the rear door
switch (LH) in order to check the ground circuit to the rear
door switch (LH).

NOTE:

Check that the rear door switch (LH) is grounded to

the vehicle body by means of its mounting screw.
Remove the cap, and measure the resistance value between the
lower metal part and the ground.

｠

The resistance should equal 2 ohms or less.

Q:Is the measured resistance 2 ohms or less?

YES:

 Go to Step 4.

NO:

 Check the fit of the switch, and repair if necessary.

Check that the input signal of rear door switch (LH) is
normal.

STEP 4. Check ETACS-ECU connector C-313 for loose,
corroded or damaged terminals, or terminals pushed back
in the connector.

Q:Is ETACS-ECU connector C-313 in good condition?

YES:

 Go to Step 5.

NO:

 Repair or replace the damaged component(s). Refer to

GROUP 00E, Harness Connector Inspection P.00E-2. Check
that the input signal of rear door switch (LH) is normal.

STEP 5. Check the wiring harness between driver's door
switch connector D-17 (terminal 3) and ETACS-ECU
connector C-313 (terminal 7).

Q:Is the wiring harness between rear door switch connector

D-17  (terminal  3)  and  ETACS-ECU  connector  C-313

(terminal 7) in good condition?

YES:

 Replace the ETACS-ECU. Check that the input signal

of rear door switch (LH) is normal.

NO:

 The wiring harness may be damaged or the connector

(s) may have loose, corroded or damaged terminals, or
terminals pushed back in the connector. Repair the wiring
harness as necessary. Check that the input signal of rear
door switch (LH) is normal.

ETACS

54Ad-79

DIAGNOSIS

Inspection Procedure 8: ETACS-ECU does not receive any signal from the rear door
switch (RH).

M15410600071USA0000010000

ETACS-
ECU

REAR DOOR
SWITCH (RH)

Rear Door Switch (RH) Input Circuit

ZC6008780018

Connector: C-313

C-313 (BR)

ZC6008800008

Connector: D-07

TECHNICAL DESCRIPTION (COMMENT)
If there is an error to the rear door switch (RH) input
signal, the rear door switch (RH) signal is no longer
output to the communication line.

TROUBLESHOOTING HINTS

｠

The rear door switch (RH) may be defective

｠

The ETACS-ECU may be defective

｠

The wiring harness or connectors may have loose,
corroded,  or  damaged  terminals,  or  terminals
pushed back in the connector

54Ad-80

ETACS

DIAGNOSIS

DIAGNOSIS

Required Special Tools:

｠

MB991223: Harness Set

｠

MB992006: Extra Fine Probe

STEP 1. Check rear door switch (RH) connector D-07 for
loose, corroded or damaged terminals, or terminals pushed
back in the connector.

Q:Is  rear  door  switch  (RH)  connector  D-07  in  good

condition?

YES:

 Go to Step 2.

NO:

 Repair or replace the damaged component(s). Refer to

GROUP 00E, Harness Connector Inspection P.00E-2. Check
that the input signal of rear door switch (RH) is normal.

STEP 2. Check the rear door switch (RH).
Remove the rear door switch (RH). Then check the continuity
between the switch terminals and the switch body.

Switch position

Tester
connection

Specified condition

Released

3 - switch body

Less than 2 ohms

Pressed

3 - switch body

Open circuit

Q:Is the rear door switch in good condition?

YES:

 Go to Step 3.

NO:

 Replace the rear door switch (RH). Check that the

input signal of rear door switch (RH) is normal.

STEP 3. Measure at the lower metal part of the rear door
switch (RH) in order to check the ground circuit to the rear
door switch (RH).

NOTE:

Check that the rear door switch (RH) is grounded to

the vehicle body by means of its mounting screw.
Remove the cap, and measure the resistance value between the
lower metal part and the ground.

｠

The resistance should equal 2 ohms or less.

Q:Is the measured resistance 2 ohms or less?

YES:

 Go to Step 4.

NO:

 Check the fit of the switch, and repair if necessary.

Check that the input signal of rear door switch (RH) is
normal.

STEP 4. Check ETACS-ECU connector C-313 for loose,
corroded or damaged terminals, or terminals pushed back
in the connector.

Q:Is ETACS-ECU connector C-313 in good condition?

YES:

 Go to Step 5.

NO:

 Repair or replace the damaged component(s). Refer to

GROUP 00E, Harness Connector Inspection P.00E-2. Check
that the input signal of rear door switch (RH) is normal.

ETACS

54Ad-81

DIAGNOSIS

STEP 5. Check the wiring harness between driver's door
switch connector D-07 (terminal 3) and ETACS-ECU
connector C-313 (terminal 8).

Q:Is the wiring harness between rear door switch connector

D-07  (terminal  3)  and  ETACS-ECU  connector  C-313

(terminal 8) in good condition?

YES:

 Replace the ETACS-ECU. Check that the input signal

of rear door switch (RH) is normal.

NO:

 The wiring harness may be damaged or the connector

(s) may have loose, corroded or damaged terminals, or
terminals pushed back in the connector. Repair the wiring
harness as necessary. Check that the input signal of rear
door switch (RH) is normal.

Inspection Procedure 9: ETACS-ECU does not receive any signal from the liftgate
switch.

M15410600073USA0000010000

Liftgate Switch Input Circuit

ETACS-
ECU

LIFTGATE
SWITCH

ZC6008780018

Connector: C-313

C-313 (BR)

ZC6008800010

Connector: D-12

54Ad-82
