STEP 3. Using scan tool MB991958, Check whether the
diagnostic trouble code is reset.
ZC501967
AC404789
ZC5019680000
MB991824
MB991827
MB991910
Data link
connector
To prevent damage to scan tool MB991958, always turn the
ignition switch to the "LOCK" (OFF) position before
connecting or disconnecting scan tool MB991958.
(1)
Connect scan tool MB991958. Refer to "How to connect scan
tool P.54Ac-58."
(2)
Turn the ignition switch to the "ON" position.
(3)
Erase the DTC.
(4)
Turn the ignition switch from "LOCK" (OFF) position to "ON"
position.
(5)
Check if DTC is set.
Q:Is DTC 24 set?
YES:
Go to Step 4.
NO:
The procedure is complete.
STEP 4. Check raer height sensor connector D-118 for
loose, corroded or damaged terminals, or terminals pushed
back in the connector.
Q:Is rear height sensor connector D-118 in good condition?
YES:
Go to Step 5.
NO:
Repair the damaged parts.
STEP 5. check rear height sensor.
Check that the rear height sensor is normal (Refer to P.
54Ac-180).
Q:Do rear height sensor work normal?
YES:
Go to Step 6.
NO:
Replace the rear height sensor.
STEP 6. Using scan tool MB991958, Check whether the
diagnostic trouble code is reset.
(1)
Turn the ignition switch to the "ON" position.
(2)
Erase the DTC.
(3)
Turn the ignition switch from "LOCK" (OFF) position to "ON"
position.
(4)
Check if DTC is set.
Q:Is DTC 24 set?
YES:
Go to Step 7.
NO:
The procedure is complete.
LIGHTING
54Ac-73
DIAGNOSIS
