CENTRALIZED JUNCTION

CIRCUIT DIAGRAMS

90-13

24

Fusible link No.36

Fusible
link

30

Pink

Starter

25

26

40

Green

ABS-ECU and ASC-ECU

27

30

Pink

ABS-ECU and ASC-ECU

28

30

Pink

Condenser fan motor, condenser fan
relay and fan control relay

29

40

Green

Radiator fan motor and radiator fan
relay

30

Fuse

30

Green

Fuse No.7 to 9 in passenger
compartment

31

30

Green

Audio amplifier

32

MFI relay

33

Battery

Fusible
link

120

Generator

34

80

Fuse Nos.2, 4, 5, 10, 11, 12, 14, 15,
17, 18, 20 and No.23 to 25 in
passenger compartment

35

80

36

120

Fuse No.1 to 32 in engine
compartment, headlight relay (High),
headlight relay (Low) and MFI relay

37

Fusible link No.33/
Generator

80

Fuse Nos.1, 3, 6, 13, 16, 19, 21 and
22 in passenger compartment and
blower relay

No. Power supply circuit Name

Rated
capacity (A)

Housing
color

Load circuit

CENTRALIZED JUNCTION

CIRCUIT DIAGRAMS

90-14

ZC6005030000

3

2

1

16 17

31 32

18 19

20 21

23

22

5

25

4

6

7

8

9

10

11

12

13

14

15

24

Relay box

27

26

29

28

30

Front of
vehicle

ZC6005020000

Fusible link box connected directly to battery positive terminal

33

35

36

37

34

Front of vehicle

CENTRALIZED JUNCTION

CIRCUIT DIAGRAMS

90-15

PASSENGER COMPARTMENT

No. Power supply circuit Name

Rated
capacity (A)

Housing
color

Load circuit

1

Fusible link No.37

Fusible
link

30

Pink

Blower motor

2

Fusible link No.34

Fuse

15

Blue

ETACS-ECU, high-mounted stoplight,
rear combination light, shift switch
assembly and spare connector (for
switch box)

3

Fusible link No.37

10

Red

4

ETACS-ECU (ACC
relay 3)

30

Green

ETACS-ECU, washer motor and
windshield wiper motor

5

Fusible link No.34

10

Red

Data link connector

6

Fusible link No.37

20

Yellow

ETACS-ECU, front door lock actuator,
liftgate lock actuator and rear door
lock actuator

7

Fusible link No.30

15

Blue

Audio visual navigation unit, CAN box
unit, center panel unit, hands free
module, radio and CD player or CD
changer, rear display unit, satellite
radio tuner and spare connector (for
rear display)

8

7.5

Brown

A/C-ECU, column switch,
combination meter, ETACS-ECU, key
reminder switch, KOS-ECU, power
window relay and wireless control
module

9

15

Blue

Center panel unit, combination meter
and key reminder switch

10

Fusible link No.34

15

Blue

ETACS-ECU

11

ETACS-ECU (ACC
relay 3)

15

Blue

ETACS-ECU and rear wiper motor

12

ETACS-ECU (IG1
relay)

7.5

Brown

AWD-ECU, A/C control panel, A/C-
ECU, A/T control relay, ABS-ECU, AC
inverter, center panel unit, column
switch, combination meter, headlight
automatic leveling-ECU, KOS-ECU,
rear window defogger relay, shift
switch assembly, SRS-ECU, steering
wheel sensor, sunroof motor
assembly and wireless control
module

13

ETACS-ECU (ACC
relay 2)

15

Blue

14

Fusible link No.34

10

Red

Ignition switch circuit

15

20

Yellow

Sunroof motor assembly

CENTRALIZED JUNCTION

CIRCUIT DIAGRAMS

90-16

16

ETACS-ECU (ACC
relay 2)

Fuse

10

Red

CAN box unit, door mirror assembly,
radio and CD player or CD changer,
rear display unit and spare connector
(for rear display)

17

Fusible link No.34

10

Red

AWD-ECU and occupant
classification-ECU

18

ETACS-ECU (IG1
relay)

7.5

Brown

Audio visual navigation unit, backup
light switch, spare connector (for
switch box), SRS-ECU and
transmission control module

19

Fusible link No.37

15

Blue

Accessory socket and ETACS-ECU

20

Fusible link No.34

Fusible
link

30

Pink

Front power window motor (RH),
power window main switch and rear
power window motor

21

Fusible link No.37

30

Pink

Rear window defogger relay

22

Rear window defogger
relay

Fuse

7.5

Brown

Door mirror assembly

23

Fusible link No.34

15

Blue

AC inverter

24

25

Transpare
nt

Foot light and power seat assembly

25

30

Green

Heated seat

No. Power supply circuit Name

Rated
capacity (A)

Housing
color

Load circuit
