Mitsubishi Outlander XL. Manual - part 12

REAR BODY

M40200000080USA0000010000

ZB5004840000

51

52

53

54

55

56

51

52

53

54

55

56

Body center point

Body center point

mm (in)

  518

(20.4)

  680

(26.8)

  951

(37.4)

  508

(20.0)

  960

(37.8)

  974

(38.3)

  700

(27.6)

1,259

(49.6)

1,003

(39.5)

1,282

(50.5)

1,139

(44.8)

1,102

(43.4)

1,354

(53.3)

1,364

(53.7)

1,073

(42.2)

1,352

(53.2)

1,014

(39.9)

1,522

(59.9)

No. Standard measurement point

Hole shape Size mm (in)

51

Center of liftgate hinge mounting hole

Round

12 (0.5)

52

Center of liftgate gas spring mounting hole

Round

12 (0.5)

53

Center of rear combination light mounting hole

Round

8 (0.3)

54

Center of liftgate lower striker mounting hole

Round

14 (0.6)

55

Rear end crossmember outer body center point

-

-

56

Center of rear bumper beam mounting hole

Round

12 (0.5)

AB501534

ZB5004850000

51



AB501535

ZB500486

52, 53

0000

52

53



AB501538

ZB5004870000

54

BODY DIMENSIONS

2-17

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

AB501537

ZB5004880000

55



AB501536

ZB5004890000

56

INTERIOR

M40200000090USA0000010000

0000

37

36

38

40

41

43

45

44

42

39

mm (in)

ZB500490

1,385

(54.5)

1,260

(49.6)

1,211

(47.7)

1,377

(54.2)

1,387

(54.6)

1,430

(56.3)

1,430

(56.3)

1,430

(56.3)

1,430

(56.3)

1,439

(56.7)

AB501483

ZB5004910000

36

37

38

39

40

41

43

42

44

45

57

58

Body center point

Body center point

mm (in)

  767

(30.2)

  783

(30.8)

  795

(31.3)

  726

(28.6)

1,232

(48.5)

1,002

(39.4)

1,205

(47.4)

1,187

(46.7)

1,180

(46.5)

1,221

(48.1)

2-18

BODY DIMENSIONS

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

AB501484

ZB500492

59

61

60

0000

Body center point

mm (in)

  954

(37.6)

  675

(26.6)

  812

(32.0)

1,159

(45.6)

1,093

(43.0)

No. Standard measurement point

Hole shape Size mm (in)

36

Front pillar positioning notch (upper)

-

-

37

Front pillar positioning notch (lower)

-

-

38

Side roof rail positioning notch (front)

-

-

39

Side sill positioning notch (front)

-

-

40

Center pillar positioning notch (upper)

-

-

41

Center pillar positioning notch (lower)

-

-

42

Side roof rail positioning notch (rear)

-

-

43

Side sill positioning notch (rear)

-

-

44

Quarter panel positioning notch (upper)

-

-

45

Quarter panel positioning notch (lower)

-

-

57

Center of parking brake lever mounting hole (Body center point)

Round

11 (0.4)

58

Rear floor pan front body center point

-

-

59

Rear floor pan rear notch (Body center point)

-

-

60

Center of rear shock absorber mounting hole

Round

14 (0.6)

61

Center of rear end trim mounting hole

Round

7 (0.3)

AB501539

ZB5004730000

36



AB501554

57

0000

ZB500493



AB501555

ZB500494

58

0000

BODY DIMENSIONS

2-19

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

AB501556

ZB500495

59

0000



AB501557

ZB500496

60

0000



AB501558

ZB500497

61

0000

ZB501485

ZB5004980000

63

64

65

66

62

Body center point

mm (in)

  756

(29.8)

  786

(30.9)

  788

(31.0)

  767

(30.2)

1,436

(56.5)

1,429

(56.3)

1,433

(56.4)

1,428

(56.2)

 140

(5.5)

 130

(5.1)

No. Standard measurement point

Hole shape Size mm (in)

62

Tip of instrument panel bracket center (Body center point)

-

-

63

Center of deck crossmember mounting hole (left-upper)

Round

9 (0.4)

64

Center of deck crossmember mounting hole (left-lower)

Round

9 (0.4)

65

Center of deck crossmember mounting hole (right-upper)

Round

13 (0.5)

66

Center of deck crossmember mounting hole (right-lower)

Round

13 (0.5)

AB501559

ZB500499

62

0000



AB501560

ZB500500

63, 64

63

64

0000



ZB500501

65, 66

65

66

0000

AB501561

2-20

BODY DIMENSIONS

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)
