Mitsubishi Outlander XL. Manual - part 11

No. Standard measurement point

Hole
shape

Size mm (in)

21

Front end crossmember upper positioning lug (Body center point)

-

-

22

Center of front bumper bracket positioning hole

Round

13 (0.5)

23

Center of front bumper bracket positioning hole

Round

13 (0.5)

24

Center of front bumper beam mounting hole

Round

9 (0.4)

25

Center of front bumper beam mounting hole

Round

9 (0.4)

26

Center of front bumper beam mounting hole

Round

9 (0.4)

27

Center of front end upper bar mounting hole

Round

6.6 (0.3)

28

Center of front end upper bar mounting hole

Round

6.6 (0.3)

29

Front sidemember inner positioning lug

-

-

30

Front sidemember inner positioning lug

-

-

31

Center of front end upper bar side positioning hole

Round

5 (0.2)

32

Center of front strut mounting hole

Round

11.5 (0.5)

33

Cowl top lower panel positioning notch (Body center point)

-

-

34

Center of hood hinge mounting hole

Round

9 (0.4)

35

Corner of roof panel

-

-

AB501562

ZB500458

21, 22

0000

22

21



AB501521

ZB5004590000

23



AB501563

ZB5004600000

24

25

24, 25

AB501522

ZB5004610000

26



AB501564

ZB5004620000

27



AB501565

ZB5004630000

28

BODY DIMENSIONS

2-13

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

AB501533

ZB5004640000

29



AB501493

ZB5004650000

30



AB501566

ZB5004660000

31

AB501567

ZB5004670000

32



AB501568

ZB5004680000

33



AB501569

ZB5004690000

34

AB501570

ZB5004700000

35

SIDE BODY

M40200000070USA0000010000

AB501356

ZB5004710000

36

37

38

39

41

40

42

43

44

45

mm (in)

  747

(29.4)

  861

(33.9)

  869

(34.2)

  645

(25.4)

  727

(28.6)

  966

(38.0)

  762

(30.0)

  855

(33.7)

  707

(27.8)

1,208

(47.6)

1,144

(45.0)

1,122

(44.2)

1,105

(43.5)

2-14

BODY DIMENSIONS

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

AB501357

ZB500472

47

46

38

49

48

42

50

0000

mm (in)

  979

(38.5)

  379

(14.9)

  321

(12.6)

  985

(38.8)

  901

(35.5)

  711

(28.0)

1,113

(43.8) 1,194

(47.0)

1,090

(42.9)

1,116

(43.9)

No. Standard measurement point

Hole shape Size mm (in)

36

Front pillar positioning notch (upper)

-

-

37

Front pillar positioning notch (lower)

-

-

38

Side roof rail positioning notch (front)

-

-

39

Side sill positioning notch (front)

-

-

40

Center pillar positioning notch (upper)

-

-

41

Center pillar positioning notch (lower)

-

-

42

Side roof rail positioning notch (rear)

-

-

43

Side sill positioning notch (rear)

-

-

44

Quarter panel positioning notch (upper)

-

-

45

Quarter panel positioning notch (lower)

-

-

46

Center of front door hinge mounting hole (upper)

Round

11 (0.4)

47

Center of front door hinge mounting hole (lower)

Round

11 (0.4)

48

Center of rear door hinge mounting hole (upper)

Round

11 (0.4)

49

Center of rear door hinge mounting hole (lower)

Round

11 (0.4)

50

Center of rear door switch mounting hole

Round

5 (0.2)

AB501539

ZB5004730000

36



AB501545

ZB500474

37, 47

0000

37

47



AB501546

ZB500475 0000

38

BODY DIMENSIONS

2-15

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

AB501547

ZB5004760000

40



AB501548

ZB5004770000

49

41

41, 43, 49

43



AB501549

ZB5004780000

42

AB501550

ZB5004790000

44



AB501551

ZB5004800000

45



AB501553

ZB5004810000

46

AB501553

ZB5004820000

48



AB501544

ZB5004830000

50

2-16

BODY DIMENSIONS

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)
