Mitsubishi Outlander GS45X. Manual - part 474





CAMSHAFT

TSB Revision

ENGINE MECHANICAL <2.4L ENGINE>

11A-27

Required Special Tool:

• MB992103: Chain Tension Release Bar

REMOVAL SERVICE POINTS

.

<<A>> ROCKER COVER ASSEMBLY REMOVAL

Loosen the rocker cover assembly mounting bolts in the order
of number shown in the figure, and remove the rocker cover
assembly.

.

Camshaft removal steps

1.

Engine upper cover

Ignition coil (Refer to GROUP 16,
Ignition System

− Ignition Coil

P.16-48

)

2.

Breather hose connection

3.

PCV hose connection

4.

Control wiring harness
connection

<<

A

>>

>>

G

<<

5.

Rocker cover assembly

6.

Rocker cover gasket

<<

B

>>

Number 1 cylinder compression
top dead center setting (only at
removal.)

Valve clearance adjustment
(Refer to

P.11A-13

) (only at

installation.)

7.

Service hole bolt

<<

C

>>

Camshaft and camshaft sprocket
assembly (exhaust side) removal
preparatory operation (only at
removal.)

<<

D

>>

>>

F

<<

8.

Front camshaft bearing cap

>>

E

<<

9.

Camshaft bearing

<<

E

>>

>>

D

<<

10. Oil feed camshaft bearing cap

(exhaust side)

<<

E

>>

>>

D

<<

11. Camshaft bearing cap (exhaust

side)

<<

E

>>

>>

D

<<

12. Camshaft bearing cap (exhaust

side)

<<

E

>>

>>

D

<<

13. Thrust camshaft bearing cap

(exhaust side)

<<

F

>>

>>

E

<<

14. Camshaft and camshaft sprocket

assembly (exhaust side)

<<

G

>>

>>

B

<<

15. Camshaft sprocket (exhaust side)

<<

G

>>

>>

B

<<

16. Camshaft (exhaust side)

>>

E

<<

17. Camshaft bearing

<<

E

>>

>>

D

<<

18. Oil feed camshaft bearing cap

(intake side)

<<

E

>>

>>

D

<<

19. Camshaft bearing cap (intake

side)

<<

E

>>

>>

D

<<

20. Camshaft bearing cap (intake

side)

<<

E

>>

>>

D

<<

21. Thrust camshaft bearing cap

(intake side)

>>

C

<<

22. Camshaft and camshaft sprocket

assembly (intake side)

<<

G

>>

>>

B

<<

23. Camshaft sprocket (intake side)

<<

G

>>

>>

B

<<

24. Camshaft (intake side)

Oil feed control valve removal
steps

1.

Engine upper cover

Drive belt (Refer to

P.11A-21

)

<<

H

>>

Power steering oil pump
assembly (Refer to GROUP 37,
Power Steering Oil Pump

P.37-48

).

<<

I

>>

>>

A

<<

25. Intake oil feeder control valve

>>

A

<<

26. O-ring

<<

I

>>

>>

A

<<

27. Exhaust oil feeder control valve

>>

A

<<

28. O-ring

Camshaft removal steps

AC506743

AD

3

6

1

9

5

2

10

4

8

7

11

12

13

14

15

16

17

18

Engine front

CAMSHAFT

TSB Revision

ENGINE MECHANICAL <2.4L ENGINE>

11A-28

<<B>> CYLINDER NO. 1 COMPRESSION TOP
DEAD CENTER SETTING

CAUTION

Never turn the crankshaft counterclockwise.
1. Turn the crankshaft clockwise so that the camshaft sprocket

timing marks become horizontal to the cylinder head upper
surface, and set the cylinder No. 1 to the top dead center of
compression. At this time, check that the crankshaft pulley
timing mark is in the 0-degree position of the ignition timing
indicator of the timing chain case assembly.

2. Put paint marks on both the camshaft sprocket and timing

chain at the position of camshaft sprocket timing chain
mating mark (circular hole).

.

<<C>> CAMSHAFT AND CAMSHAFT SPROCKET
ASSEMBLY (EXHAUST SIDE) REMOVAL
PREPARATORY OPERATION

1. Insert a precision flat-tipped screwdriver through the service

hole of the timing chain case, press up the timing chain
tensioner ratchet to unlock, and keep the timing chain
tensioner with that state.
NOTE: Lightly press down the tail end of the precision
flat-tipped screwdriver to press up the tip of the precision
flat-tipped screwdriver inserted to the timing chain tensioner
to unlock.

CAUTION

• When inserting special tool MB992103 into the timing

chain case assembly inside, pay attention to the posi-
tion of the timing chain to avoid damage to the timing
chain and timing chain tension side guide. Do not
insert the special tool beyond its insertion guideline.

• If unlocking the timing chain tensioner is insufficient,

the special tool cannot be inserted to the insertion
guideline. Do not insert the special tool forcibly, follow
Step 1 again to unlock the timing chain tensioner and
insert the special tool.

AC506744

Paint
markings

Camshaft sprocket
timing marks

Timing chain
mating mark

Timing chain
mating mark

AC

Cylinder head upper surface

AC509155

AC

Section A-A

A

A

Precision flat-tipped
screwdriver

Service hole

Crankshaft pulley

Service hole

Ratchet

Precision flat-tipped screwdriver

Ratchet
release hole

Timing chain
tensioner

Ratchet

Ratchet
release hole

Timing chain tensioner
construction diagram

CAMSHAFT

TSB Revision

ENGINE MECHANICAL <2.4L ENGINE>

11A-29

2. With the timing chain tensioner unlocked, insert special tool

MB992103 inside the timing chain case assembly along the
tension side of the timing chain until the insertion guide line
aligns with the upper surface of the timing chain case
assembly (Figure A).
NOTE: With the timing chain tensioner unlocked, insert the
special tool along the tension side of the timing chain,
according to the special tool top shape. The special tool can
be inserted smoothly to the position where the special tool
insertion guide line aligns with the timing chain case assem-
bly top surface (Figure B), and the spread timing chain ten-
sion side guide can be held (Figure C).

3. With the special tool inserted up to the insertion guide line,

press the special tool against the intake side camshaft
sprocket and spread and hold the timing chain tension side
guide.

4. Remove the flat-tipped precision screwdriver unlocking the

timing chain tensioner.

AC507118

AC

Timing chain

MB992103

Insertion standard line

AC508123

AC509159AB

MB992103

MB992103

Timing chain tensioner

Timing chain tension
side guide

Timing chain
tension
side guide

Camshaft
sprocket
(intake side)

Valve timing chain
(tension side)

A

B

C

CAMSHAFT

TSB Revision

ENGINE MECHANICAL <2.4L ENGINE>

11A-30

CAUTION

The timing chain may snag on by other parts. After sag-
ging the timing chain, never rotate the crankshaft.
5. With the timing chain tension side guide spread, hook the

special tool over the hexagon part of the camshaft on the
exhaust side, and turn the camshaft clockwise to apply slack
to the timing chain between the camshaft sprockets.

.

<<D>> FRONT CAMSHAFT BEARING CAP
ASSEMBLY REMOVAL

CAUTION

Be careful not to drop the camshaft bearing.
Loosen the mounting bolts of front camshaft bearing cap in the
order of number shown in the figure, and remove the front cam-
shaft bearing cap assembly.

.

AC506748 AC

MB992103

Timing chain

Hexagon
part of
exhaust
camshaft

AC506745

AD

1

2

3

4

Engine front

Front camshaft
bearing cap
assembly
