Mitsubishi Outlander GS45X. Manual - part 343





SOLENOID AND SOLENOID VALVE

TSB Revision

COMPONENT LOCATIONS

70-19

AC702544

Exhaust gas
recirculation valve

AC

<3.0L Engine>

H

AC702590

AC702590

I

AD

A/T control solenoid
valve assembly

A/T control solenoid
valve assembly connector

<3.0L Engine>

Centermember

Battery tray

AC702592

AC702592 AD

Shift lock
solenoid

Selector lever
assembly

J

AC900663

AC900389

AD

Electronic control
coupling solenoid
(Front)

Electronic control
coupling solenoid
(Front) connector

<S-AWC>

K

AC702589AD

Electronic control
coupling solenoid
connector

<Electronic controlled AWD>

L

Electronic control
coupling solenoid

FUSIBLE LINK, FUSE AND IOD OR STORAGE CONNECTOR

TSB Revision

COMPONENT LOCATIONS

70-20

FUSIBLE LINK, FUSE AND IOD OR STORAGE

CONNECTOR

M1701000101509

AC702589AF

Electronic control
coupling solenoid
(Center) connector

<S-AWC>

L

Electronic control
coupling solenoid
(Center)

AC702559

AC

Evaporative emission
ventilation solenoid

Spare tire

M

Name

Symbol

Name

Symbol

Fuse Nos.1 to 23 and No.31 to 32
(engine compartment relay box)

B

Fusible link Nos.21 (passenger
compartment relay box)

C

Fuse Nos.2 to 19 (ETACS-ECU)

C

Fusible link Nos.24 to 30 (engine
compartment relay box)

B

Fuse Nos.22 to 25 (passenger
compartment relay box)

C

Fusible link Nos.33 to 37 (connected
directly to battery positive terminal)

A

Fusible link No.1 and No.20
(ETACS-ECU)

C

IOD or storage connector

B

FUSIBLE LINK, FUSE AND IOD OR STORAGE CONNECTOR

TSB Revision

COMPONENT LOCATIONS

70-21

AC900431

A

B

C

AD

AC702522

AB

A

Fusible link
Nos.33 to 37

AC702520 AB

B

Fusible link
Nos.24 to 30

AC702521AB

B

Fuse Nos.1 to 23
and 31 to 32

IOD or storage
connector

AC702541

AB

C

Fusible
link No.21

Fusible link No.20

Fusible link No.1

AC702542

AB

C

Fuse Nos.22
to 25

Fuse Nos.2 to 19

OTHER DEVICES

TSB Revision

COMPONENT LOCATIONS

70-22

OTHER DEVICES

M1701005600551

GROUNDING CABLE

M1701001001334

AC900779

AC900779

A/C compressor

AB

A/C refrigerant
temperature switch

AC900362

AC900362

AD

Power steering
oil pump

<2.4L Engine>

AC900363

AC900363

AD

Generator

<3.0L Engine>
