IGNITION KEY REMINDER TONE ALARM <VEHICLES WITHOUT KOS>

TSB Revision

CIRCUIT DIAGRAMS

90-377

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

34

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

FRONT
DOOR
SWITCH (LH)

DATA LINK
CONNECTOR

KEY
REMINDER
SWITCH

WHEN
REMOVING
KEY: ON

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

IGNITION KEY REMINDER TONE ALARM <VEHICLES WITH KOS>

TSB Revision

CIRCUIT DIAGRAMS

90-378

IGNITION KEY REMINDER TONE ALARM

<VEHICLES WITH KOS>

M1901011302678

IG1
RELAY

ETACS-
ECU

FUSIBLE
LINK

36

FUSIBLE
LINK

34

IGNITION
SWITCH (IG1)

RELAY BOX

ENGINE
COMPARTMENT

PUSH
SWITCH

WHEN
REMOVING
KEY: ON

KEY
REMINDER
SWITCH

POWER
SUPPLY

POWER
DISTRIBUTION
SYSTEM

IGNITION KEY REMINDER TONE ALARM <VEHICLES WITH KOS>

TSB Revision

CIRCUIT DIAGRAMS

90-379

KOS-ECU

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

CPU

LCD

(KEY REMINDER)

NOTE

:

COMBINATION
METER

CAN
TRANSCEIVER
CIRCUIT

TONE ALARM

RHEOSTAT

: ·AIR CONDITIONING SYSTEM

·ANTI-LOCK BRAKING SYSTEM (ABS)
 AND ACTIVE STABILITY CONTROL
 SYSTEM (ASC)
·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT AND
 OIL PRESSURE WARNING LIGHT
·CHARGING SYSTEM
·COOLING SYSTEM
·CRUISE CONTROL SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOOR AJAR WARNING TONE ALARM
·ELECTRONIC CONTROLLED AWD
·FOG LIGHT
·GLOVE BOX LIGHT
·HANDS-FREE INTERFACE SYSTEM
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·INVECS-II 6A/T
·INVECS-III CVT

·METER AND GAUGE
·MFI SYSTEM
·PARKING BRAKE REMINDER TONE
 ALARM
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·S-AWC
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT SYSTEM
 (SRS)
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT
 AND LIGHTING MONITOR TONE ALARM
·TIRE PRESSURE MONITORING SYSTEM
 (TPMS)
·TURN-SIGNAL LIGHT
 AND HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

·AIR CONDITIONING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·REAR WIPER AND WASHER
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT
 AND LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TURN-SIGNAL LIGHT
 AND HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

JOINT
CONNECTOR
(CAN1)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

IGNITION KEY REMINDER TONE ALARM <VEHICLES WITH KOS>

TSB Revision

CIRCUIT DIAGRAMS

90-380

IGNITION KEY REMINDER TONE ALARM <VEHICLES WITH KOS> (CONTINUED)
