SUNROOF

TSB Revision

CIRCUIT DIAGRAMS

90-369

NOTES

POWER SEAT

TSB Revision

CIRCUIT DIAGRAMS

90-370

POWER SEAT

M1901010401163

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

34

FOOT LIGHT

POWER SEAT
ASSEMBLY

FRONT HEIGHT SWITCH

FRONT HEIGHT MOTOR

CIRCUIT
BREAKER

REAR HEIGHT SWITCH

REAR HEIGHT MOTOR

CIRCUIT
BREAKER

PASSENGER
COMPARTMENT

RELAY BOX

POWER SEAT

TSB Revision

CIRCUIT DIAGRAMS

90-371

SLIDE SWITCH

SLIDE MOTOR

CIRCUIT
BREAKER

RECLINING SWITCH

RECLINING MOTOR

CIRCUIT
BREAKER

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

HEATED SEAT

TSB Revision

CIRCUIT DIAGRAMS

90-372

HEATED SEAT

M1901010702394

ETACS-ECU

FUSIBLE
LINK

34

POWER
DISTRIBUTION
SYSTEM

IGNITION
SWITCH (IG1)

TAILLIGHT
CONTROL
CIRCUIT

HEATED
SEAT
RELAY

IG1
RELAY

RELAY BOX

PASSENGER
COMPARTMENT

·GLOVE BOX LIGHT
·SPARE CONNECTOR
 (FOR TRAILER LIGHTS)
·TAILLIGHT, POSITION
 LIGHT, REAR SIDE
 MARKER LIGHT, LICENSE
 PLATE LIGHT AND LIGHTING
 MONITOR TONE ALARM
