CRUISE CONTROL SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-361

NOTES

TIRE PRESSURE MONITORING SYSTEM (TPMS)

TSB Revision

CIRCUIT DIAGRAMS

90-362

TIRE PRESSURE MONITORING SYSTEM (TPMS)

M1901003900958

34

FUSIBLE
LINK

36

FUSIBLE
LINK

IGNITION
SWITCH (IG1)

ETACS-
ECU

<VEHICLES
WITHOUT KOS>

CAN DRIVE CIRCUIT

IG1
RELAY

RECEIVER

POWER
DISTRIBUTION
SYSTEM

WIRELESS CONTROL MODULE

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS)
 AND ACTIVE STABILITY CONTROL
 SYSTEM (ASC)
·DAYTIME RUNNING LIGHT (DRL)
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·INVECS-II 6A/T
·INVECS-III CVT
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE
 ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT
 AND LIGHTING MONITOR
 TONE ALARM
·TURN-SIGNAL LIGHT
 AND HAZARD WARNING LIGHT
·WINDSHIELD WIPER
 AND WASHER

:

NOTE

POWER
SUPPLY

RELAY BOX

ENGINE
COMPARTMENT

JOINT CONNECTOR
(CAN1)

TIRE PRESSURE MONITORING SYSTEM (TPMS)

TSB Revision

CIRCUIT DIAGRAMS

90-363

RECEIVER

RECEIVER ANTENNA MODULE

<VEHICLES WITH KOS>

TPMS
TRANSMITTER

ANTENNA

·FRONT TIRE (LH/RH)
·REAR TIRE (LH/RH)

·PRESSURE SENSOR
·ROLL SWITCH

KOS-ECU

·METER AND GAUGE
·MITSUBISHI MULTI-COMMUNICATION
 SYSTEM (MMCS)
·REAR SEAT ENTERTAINMENT SYSTEM
·REAR WIPER AND WASHER
·SPARE CONNECTOR
 (FOR REAR DISPLAY)
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT
 AND LIGHTING MONITOR
 TONE ALARM
·THEFT-ALARM SYSTEM
·TURN-SIGNAL LIGHT AND HAZARD
 WARNING LIGHT
·UNIVERSAL SERIAL BUS (USB) BOX
·WINDSHIELD WIPER AND WASHER

:  ·AIR CONDITIONING SYSTEM

·AUDIO SYSTEM
·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT AND OIL
 PRESSURE WARNING LIGHT
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT,
 LUGGAGE COMPARTMENT
 LIGHT AND IGNITION KEY
 HOLE ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEADLIGHT MANUAL LEVELING
 SYSTEM
·IGNITION KEY REMINDER
 TONE ALARM
·KEYLESS OPERATING
 SYSTEM (KOS)

POWER
SUPPLY

CONTROL CIRCUIT

JOINT CONNECTOR
(CAN1)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

TIRE PRESSURE MONITORING SYSTEM (TPMS)

TSB Revision

CIRCUIT DIAGRAMS

90-364

TIRE PRESSURE MONITORING SYSTEM (TPMS) (CONTINUED)

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

5

FUSE

DATA LINK
CONNECTOR

ENGINE
CONTROL
MODULE

FRONT SIDE

JOINT
CONNECTOR
(CAN2)

JOINT
CONNECTOR
(CAN3)
