CRUISE CONTROL SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-357

HALL IC

ENGINE
CONTROL
MODULE

ACCELERATOR
PEDAL POSITION
SENSOR

THROTTLE
ACTUATOR
CONTROL
MOTOR

THROTTLE
BODY
ASSEMBLY

HALL IC

(SUB)

HALL IC

(MAIN)

HALL IC

(SUB)

(MAIN)

<3.0L ENGINE>

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CRUISE CONTROL SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-358

CRUISE CONTROL SYSTEM (CONTINUED)

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

FRONT SIDE

DATA LINK
CONNECTOR

ENGINE
CONTROL
MODULE

(FUSE     )

5

ETACS-ECU

JOINT
CONNECTOR
(CAN2)

JOINT
CONNECTOR
(CAN3)

INPUT SIGNAL

·COLUMN SWITCH
 (LIGHTING SWITCH)
·LIGHTING
 CONTROL SENSOR
 <VEHICLES WITH
 AUTOMATIC LIGHT>

CRUISE CONTROL SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-359

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

COMBINATION METER

INPUT SIGNAL

ETACS-ECU

ASC-ECU

(FUSE     )

12

ETACS-ECU

CPU

CAN
TRANSCEIVER
CIRCUIT

LED DRIVE
CIRCUIT

·OUTPUT SHAFT
 SPEED SENSOR
 <3.0L ENGINE>
·SECONDARY PULLEY
 SPEED SENSOR
 <2.4L ENGINE>
·TRANSMISSION
 RANGE SWITCH (N)

TRANSAXLE
CONTROL
MODULE

<VEHICLES WITH ASC>

JOINT
CONNECTOR
(CAN1)

NOTE

: 2.4L ENGINE
: 3.0L ENGINE

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE
Y : YELLOW     SB : SKY BLUE     BR :BROWN     O : ORANGE     GR : GRAY
R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS)
 AND ACTIVE STABILITY CONTROL
 SYSTEM (ASC)
·CENTRAL DOOR LOCKING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE
 COMPARTMENT LIGHT AND
 IGNITION KEY HOLE
 ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER TONE
 ALARM <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·KEYLESS OPERATING SYSTEM
 (KOS)
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
 REAR SIDE MARKER LIGHT,
 LICENSE PLATE LIGHT AND
 LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING
 SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND HAZARD
 WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

CRUISE CONTROL SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-360

CRUISE CONTROL SYSTEM (CONTINUED)

CLOCK
SPRING

COMBINATION
METER

RHEOSTAT

ENGINE
CONTROL
MODULE

36

FUSIBLE
LINK

RELAY BOX

ENGINE
COMPARTMENT

CRUISE
CONTROL
SWITCH

ETACS-
ECU

CPU

INTERFACE
CIRCUIT

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
 AND ACTIVE STABILITY CONTROL SYSTEM (ASC)
·AUDIO SYSTEM
·ELECTRONIC CONTROLLED AWD
·HANDS-FREE INTERFACE SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·MITSUBISHI MULTI-COMMUNICATION SYSTEM (MMCS)
·REAR SEAT ENTERTAINMENT SYSTEM
·S-AWC
·SPARE CONNECTOR (FOR REAR DISPLAY)
·TURN-SIGNAL LIGHT AND HAZARD WARNING LIGHT
·UNIVERSAL SERIAL BUS (USB) BOX

·AUDIO SYSTEM
·HANDS-FREE
 INTERFACE SYSTEM
·MITSUBISHI
 MULTI-COMMUNICATION
 SYSTEM (MMCS)
·UNIVERSAL SERIAL
 BUS (USB) BOX

THEFT-ALARM
SYSTEM

NOTE

:
