Mitsubishi Outlander GS45X. Manual - part 323
HEATED SEAT
TSB Revision
CIRCUIT DIAGRAMS
90-373
THERMOSTAT
HEATED SEAT
SWITCH
ETACS-ECU
SEAT
BACK
HEATER
HEATED SEAT
RELAY
HEATED
SEAT
ASSEMBLY
(LH)
:
NOTE
THERMOSTAT
SEAT
CUSHION
HEATER
TAILLIGHT
CONTROL CIRCUIT
·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
AND ACTIVE STABILITY CONTROL
SYSTEM (ASC)
·BRAKE WARNING LIGHT, FUEL
WARNING LIGHT AND OIL PRESSURE
WARNING LIGHT
·CENTRAL DOOR LOCKING SYSTEM
·CHARGING SYSTEM
·COOLING SYSTEM
·CRUISE CONTROL SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE
COMPARTMENT LIGHT AND IGNITION
KEY HOLE ILLUMINATION LIGHT
·DOOR AJAR WARNING TONE ALARM
·ELECTRONIC CONTROLLED AWD
·FOG LIGHT
·S-AWC
·SEAT BELT WARNING TONE
ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
REAR SIDE MARKER LIGHT,
LICENSE PLATE LIGHT
AND LIGHTING MONITOR
TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
MONITORING SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
HAZARD WARNING LIGHT
·WINDSHIELD WIPER
AND WASHER
·GLOVE BOX LIGHT
·HANDS-FREE INTERFACE
SYSTEM
·HEADLIGHT
·HEATED DOOR MIRROR
·IGNITION KEY REMINDER TONE
ALARM <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·KEYLESS OPERATING SYSTEM
(KOS)
·METER AND GAUGE
·MFI SYSTEM
·PARKING BRAKE REMINDER
TONE ALARM
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE SI : SILVER
