ELECTRONIC CONTROLLED AWD
TSB Revision
CIRCUIT DIAGRAMS
90-345
CPU
ETACS-ECU
CAN TRANSCEIVER
CIRCUIT
LCD
·2WD
·4WD AUTO
·4WD LOCK
·ANTI-LOCK
BRAKING SYSTEM
(ABS) AND ACTIVE
STABILITY CONTROL
SYSTEM (ASC)
·AUDIO SYSTEM
·CRUISE
CONTROL SYSTEM
·HANDS-FREE
INTERFACE SYSTEM
·HEADLIGHT MANUAL
LEVELING SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·MITSUBISHI
MULTI-COMMUNICATION
SYSTEM (MMCS)
·REAR SEAT
ENTERTAINMENT SYSTEM
·SPARE CONNECTOR
(FOR REAR DISPLAY)
·UNIVERSAL SERIAL BUS
(USB) BOX
ETACS-ECU
(FUSE )
12
JOINT
CONNECTOR
(CAN1)
(CAN DRIVE CIRCUIT)
·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
AND ACTIVE STABILITY CONTROL
SYSTEM (ASC)
·CENTRAL DOOR LOCKING SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE
COMPARTMENT LIGHT AND
IGNITION KEY HOLE
ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER TONE
ALARM <VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·KEYLESS OPERATING SYSTEM
(KOS)
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
REAR SIDE MARKER LIGHT,
LICENSE PLATE LIGHT AND
LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING
SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND HAZARD
WARNING LIGHT
·WINDSHIELD WIPER AND WASHER
:
NOTE
WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE SI : SILVER
