IMMOBILIZER SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-337

FRONT SIDE

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

5

FUSE

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

JOINT
CONNECTOR
(CAN1)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

IMMOBILIZER SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-338

IMMOBILIZER SYSTEM (CONTINUED)

34

FUSIBLE
LINK

IGNITION
SWITCH (IG1)

30

RELAY BOX
(FUSE      )

ETACS-
ECU

CAN DRIVE
CIRCUIT

IMMOBILIZER
ANTENNA

ID
CODE

TRANSPONDER

<VEHICLES
WITHOUT KOS>

IG1
RELAY

POWER
DISTRIBUTION
SYSTEM

WIRELESS CONTROL MODULE

JOINT CONNECTOR
(CAN1)

IMMOBILIZER SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-339

IMMOBILIZER
ANTENNA

CAN DRIVE CIRCUIT

KEYLESS
OPERATION
KEY

ID
CODE

TRANSPONDER

RECEIVER ANTENNA MODULE

<VEHICLES WITH KOS>

KOS-ECU

POWER
SUPPLY

JOINT CONNECTOR
(CAN1)

NOTE

:

: ·AIR CONDITIONING SYSTEM

·AUDIO SYSTEM
·BRAKE WARNING LIGHT, FUEL
 WARNING LIGHT AND OIL PRESSURE
 WARNING LIGHT
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT,
 LUGGAGE COMPARTMENT
 LIGHT AND IGNITION KEY
 HOLE ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEADLIGHT MANUAL LEVELING SYSTEM
·IGNITION KEY REMINDER TONE ALARM
·KEYLESS OPERATING SYSTEM (KOS)
·METER AND GAUGE
·MITSUBISHI MULTI-COMMUNICATION
 SYSTEM (MMCS)
·REAR SEAT ENTERTAINMENT SYSTEM
·REAR WIPER AND WASHER
·SPARE CONNECTOR (FOR REAR DISPLAY)
·TAILLIGHT, POSITION LIGHT, REAR SIDE
 MARKER LIGHT, LICENSE PLATE LIGHT
 AND LIGHTING MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TURN-SIGNAL LIGHT AND HAZARD
 WARNING LIGHT
·UNIVERSAL SERIAL BUS (USB) BOX
·WINDSHIELD WIPER AND WASHER

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS)
 AND ACTIVE STABILITY CONTROL
 SYSTEM (ASC)
·BRAKE WARNING LIGHT, FUEL
 WARNING LIGHT AND OIL PRESSURE
 WARNING LIGHT
·CHARGING SYSTEM
·COOLING SYSTEM
·CRUISE CONTROL SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOOR AJAR WARNING TONE ALARM
·ELECTRONIC CONTROLLED AWD
·FOG LIGHT
·GLOVE BOX LIGHT
·HANDS-FREE INTERFACE SYSTEM
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT

·INVECS-II 6A/T
·INVECS-III CVT
·METER AND GAUGE
·MFI SYSTEM
·PARKING BRAKE REMINDER TONE
 ALARM
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·S-AWC
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT SYSTEM
 (SRS)
·TAILLIGHT, POSITION LIGHT, REAR SIDE
 MARKER LIGHT, LICENSE PLATE LIGHT
 AND LIGHTING MONITOR TONE ALARM
·TIRE PRESSURE MONITORING SYSTEM
 (TPMS)
·TURN-SIGNAL LIGHT AND HAZARD
 WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

ELECTRONIC CONTROLLED AWD

TSB Revision

CIRCUIT DIAGRAMS

90-340

ELECTRONIC CONTROLLED AWD

M1901027000692

ETACS-
ECU

POWER
DISTRIBUTION
SYSTEM

FUSIBLE
LINK

34

IGNITION
SWITCH (IG1)

IG1
RELAY

AWD-ECU

POWER
SUPPLY

SUPPLEMENTAL
RESTRAINT SYSTEM
(SRS)

ANTI-LOCK BRAKING
SYSTEM (ABS) AND
ACTIVE STABILITY
CONTROL SYSTEM
(ASC)

SUPPLEMENTAL
RESTRAINT SYSTEM
(SRS)
