SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-333

WEIGHT
SENSOR
(FRONT: LH)

WEIGHT
SENSOR
(REAR: LH)

WEIGHT
SENSOR
(REAR: RH)

WEIGHT
SENSOR
(FRONT: RH)

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-334

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) (CONTINUED)

CENTER
PANEL
UNIT

ETACS-ECU

(FUSE     )

12

INTERFACE
CIRCUIT

SRS-ECU

AIR BAG OFF
INDICATOR
LIGHT
PASSENGER'S
SIDE

HALL IC

PASSENGER'S
SIDE

SEAT BELT
SWITCH

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-335

NOTES

IMMOBILIZER SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-336

IMMOBILIZER SYSTEM

M1901013605339

36

FUSIBLE
LINK

MFI
RELAY

ETACS-ECU

CAN DRIVE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

IGNITION
SYSTEM

ENGINE
CONTROL
MODULE

ENGINE
COMPARTMENT

RELAY BOX

JOINT
CONNECTOR
(CAN2)

JOINT
CONNECTOR
(CAN3)
