Mitsubishi Outlander GS45X. Manual - part 311

ANTI-LOCK BRAKING SYSTEM (ABS) AND ACTIVE STABILITY CONTROL SYSTEM (ASC)

TSB Revision

CIRCUIT DIAGRAMS

90-325

CPU

ETACS-ECU

(FUSE )

LED DRIVE
CIRCUIT

INTERFACE
CIRCUIT

PARKING
BRAKE
SWITCH

WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE SI : SILVER

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-326

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

M1901009703070

ACCELERO
METER

CPU

FRONT
IMPACT
SENSOR
(LH)

FRONT
IMPACT
SENSOR
(RH)

SRS-ECU

CLOCK
SPRING

DRIVER'S
AIR BAG
MODULE
(SQUIB)

CONNECTOR
LOCK SWITCH

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-327

SEAT BELT
PRE-TENSIONER (LH)

SEAT BELT
PRE-TENSIONER (RH)

LAP
PRE-TENSIONER

PASSENGER'S
(FRONT)
AIR BAG MODULE
(SQUIB)

NOTE

: CONNECTOR COUPLED : ON

CONNECTOR UNCOUPLED : OFF

CONNECTOR
LOCK SWITCH

CONNECTOR
LOCK
SWITCH

CONNECTOR
LOCK SWITCH

WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE SI : SILVER

SUPPLEMENTAL RESTRAINT SYSTEM (SRS)

TSB Revision

CIRCUIT DIAGRAMS

90-328

SUPPLEMENTAL RESTRAINT SYSTEM (SRS) (CONTINUED)

SIDE IMPACT SENSOR
(FRONT : LH)

ACCELERO
METER

CPU

SIDE IMPACT SENSOR
(REAR : LH)

SIDE-AIR BAG MODULE
(SQUIB) (LH)

CURTAIN AIR BAG MODULE
(SQUIB) (LH)

ACCELERO
METER

CONNECTOR
LOCK
SWITCH
