AUDIO SYSTEM <VEHICLES WITHOUT AUDIO AMPLIFIER>
TSB Revision
CIRCUIT DIAGRAMS
90-225
FUSIBLE
LINK
37
ACC
RELAY 2
ROOF ANTENNA
ANTENNA
AMPLIFIER
ANTENNA FEEDER CABLE
RADIO AND CD PLAYER
IGNITION
SWITCH (ACC)
COMBINATION
METER
A/C
CONTROL
PANEL
INTERFACE
CIRCUIT
INTERFACE
CIRCUIT
CPU
·REAR SEAT
ENTERTAINMENT SYSTEM
·REMOTE CONTROLLED
MIRROR
·SPARE CONNECTOR
(FOR REAR DISPLAY)
POWER
DISTRIBUTION
SYSTEM
ETACS-
ECU
:
:
NOTE
·ELECTRONIC CONTROLLED AWD
·S-AWC
·AIR CONDITIONING SYSTEM
·CENTRAL DOOR LOCKING
SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE
COMPARTMENT LIGHT AND
IGNITION KEY HOLE
ILLUMINATION LIGHT
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·IGNITION KEY REMINDER
TONE ALARM
<VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·KEYLESS OPERATING SYSTEM
(KOS)
·REAR WIPER AND WASHER
·TAILLIGHT, POSITION LIGHT,
REAR SIDE MARKER LIGHT,
LICENSE PLATE LIGHT AND
LIGHTING MONITOR TONE
ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
MONITORING SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND
WASHER
WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE SI : SILVER
<NO CONNECTION>
