Mitsubishi Outlander GS45X. Manual - part 284
REAR WINDOW DEFOGGER
TSB Revision
CIRCUIT DIAGRAMS
90-217
INTERFACE
CIRCUIT
REAR
WINDOW
DEFOGGER
INDICATOR
INTERFACE
CIRCUIT
CAN DRIVE
CIRCUIT
A/C-ECU
NOTE
: ·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING
SYSTEM (ABS)
·ANTI-LOCK BRAKING
SYSTEM (ABS) AND
ACTIVE STABILITY
CONTROL SYSTEM (ASC)
·BRAKE WARNING LIGHT,
FUEL WARNING
LIGHT AND OIL PRESSURE
WARNING LIGHT
·CENTRAL DOOR LOCKING
SYSTEM
·CHARGING SYSTEM
·COOLING SYSTEM
·CRUISE CONTROL SYSTEM
·DAYTIME RUNNING LIGHT
(DRL)
·DOME LIGHT, LUGGAGE
COMPARTMENT LIGHT
AND IGNITION KEY HOLE
ILLUMINATION LIGHT
·REAR WIPER AND WASHER
·S-AWC
·SEAT BELT WARNING
TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT
SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT,
REAR SIDE MARKER LIGHT,
LICENSE PLATE LIGHT AND
LIGHTING MONITOR
TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE
MONITORING
SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND
HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND
WASHER
·DOOR AJAR WARNING
TONE ALARM
·ELECTRONIC CONTROLLED
AWD
·FOG LIGHT
·GLOVE BOX LIGHT
·HANDS-FREE INTERFACE
SYSTEM
·HEADLIGHT
·HEATED SEAT
·IGNITION KEY REMINDER
TONE ALARM
<VEHICLES WITH KOS>
·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·KEYLESS OPERATING
SYSTEM (KOS)
·METER AND GAUGE
·MFI SYSTEM
·PARKING BRAKE
REMINDER TOME ALARM
JOINT
CONNECTOR
(CAN1)
WIRE COLOR CODE
B : BLACK LG : LIGHT GREEN G : GREEN L : BLUE W : WHITE Y : YELLOW SB : SKY BLUE
BR : BROWN O : ORANGE GR : GRAY R : RED P : PINK V : VIOLET PU : PURPLE SI : SILVER
