CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-185

NOTES

KEYLESS OPERATING SYSTEM (KOS)

TSB Revision

CIRCUIT DIAGRAMS

90-186

KEYLESS OPERATING SYSTEM (KOS)

M1901025501649

FUSIBLE
LINK

34

FUSIBLE
LINK

36

IGNITION
SWITCH (IG1)

RELAY BOX

ENGINE
COMPARTMENT

ETACS-
ECU

IG1
RELAY

POWER
SUPPLY

DATA LINK
CONNECTOR

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

KOS-ECU

FRONT SIDE

POWER
DISTRIBUTION
SYSTEM

·AIR CONDITIONING
 SYSTEM
·DAYTIME RUNNING
 LIGHT (DRL)
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·REAR WIPER AND
 WASHER
·TAILLIGHT, POSITION
 LIGHT, LICENSE PLATE
 LIGHT AND LIGHTING
 MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TURN-SIGNAL LIGHT
 AND HAZARD
 WARNING LIGHT
·WINDSHIELD WIPER
 AND WASHER

KEYLESS OPERATING SYSTEM (KOS)

TSB Revision

CIRCUIT DIAGRAMS

90-187

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

JOINT
CONNECTOR
(CAN2)

JOINT
CONNECTOR
(CAN3)

ABS-ECU

ENGINE
CONTROL
MODULE

ASC-ECU

INPUT SIGNAL

·FRONT WHEEL
 SPEED SENSOR
·REAR WHEEL
 SPEED SENSOR

NOTE

:
:
:

VEHICLES WITHOUT ASC

VEHICLES WITH ASC
·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS) AND
 ACTIVE STABILITY CONTROL SYSTEM (ASC)
·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT AND
 OIL PRESSURE WARNING LIGHT
·CHARGING SYSTEM
·COOLING SYSTEM
·CRUISE CONTROL SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOOR AJAR WARNING TONE ALARM
·ELECTRONIC CONTROLLED AWD

·FOG LIGHT
·GLOVE BOX LIGHT
·HANDS-FREE INTERFACE SYSTEM
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·INVECS-II 6A/T
·INVECS-III CVT
·METER AND GAUGE
·MFI SYSTEM
·PARKING BRAKE REMINDER
 TONE ALARM
·REAR WINDOW DEFOGGER

·REAR WIPER AND WASHER
·S-AWC
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT SYSTEM
 (SRS)
·TAILLIGHT, POSITION LIGHT, REAR SIDE
 MARKER LIGHT, LICENSE PLATE LIGHT
 AND LIGHTING MONITOR TONE ALARM
·TIRE PRESSURE MONITORING SYSTEM
 (TPMS)
·TURN-SIGNAL LIGHT AND HAZARD
 WARNING LIGHT
·WINDSHIELD WIPER AND WASHER

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

KEYLESS OPERATING SYSTEM (KOS)

TSB Revision

CIRCUIT DIAGRAMS

90-188

KEYLESS OPERATING SYSTEM (KOS) (CONTINUED)

KOS-
ECU

KEYLESS
OPERATION
KEY

OUTSIDE TRANSMISSION
ANTENNA ASSEMBLY
(PASSENGER'S SIDE)

INSIDE TRANSMISSION
ANTENNA ASSEMBLY
(FRONT)

OUTSIDE TRANSMISSION
ANTENNA ASSEMBLY
(DRIVER'S SIDE)
