CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-177

FUSIBLE
LINK

34

TURN-SIGNAL
LIGHT CONTROL
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

POWER
DISTRIBUTION
SYSTEM

TURN-SIGNAL LIGHT AND
HAZARD WARNING LIGHT

·TURN-SIGNAL LIGHT AND
 HAZARD WARNING LIGHT
·SPARE CONNECTOR
 (FOR TRAILER LIGHTS)

LIFTGATE
LOCK
RELAY

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-178

CENTRAL DOOR LOCKING SYSTEM (CONTINUED)

DOOR
LOCK
RELAY

DRIVER'S
DOOR
UNLOCK
RELAY

PASSENGER'S
DOOR
UNLOCK
RELAY

ETACS-ECU

FRONT DOOR LOCK
ACTUATOR (RH)

FRONT DOOR LOCK
ACTUATOR (LH)

LIFTGATE
LOCK
RELEASE
HANDLE

<VEHICLES
WITH KOS>

KEYLESS
OPERATING
SYSTEM (KOS)

OPEN
SWITCH

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-179

DOOR
LOCK
RELAY

PASSENGER'S
DOOR
UNLOCK
RELAY

LIFTGATE
LOCK
RELAY

REAR DOOR LOCK
ACTUATOR (LH)

REAR DOOR LOCK
ACTUATOR (RH)

LIFTGATE
LOCK
ACTUATOR

KEY
REMINDER
SWITCH
WHEN
REMOVING
KEY: ON

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

: VEHICLES WITH KOS

NOTE

CENTRAL DOOR LOCKING SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-180

CENTRAL DOOR LOCKING SYSTEM (CONTINUED)

ETACS-ECU

INTERFACE
CIRCUIT

CAN DRIVE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

TRANSAXLE
CONTROL MODULE

JOINT
CONNECTOR
(CAN3)

JOINT
CONNECTOR
(CAN2)

ABS-ECU

ASC-ECU

INPUT SIGNAL

·FRONT WHEEL
 SPEED SENSOR
·REAR WHEEL
 SPEED SENSOR

INPUT SIGNAL

TRANSMISSION
RANGE SWITCH (P)

NOTE

:
:
:
:

2.4L ENGINE
3.0L ENGINE
VEHICLES WITHOUT ASC
VEHICLES WITH ASC
