Mitsubishi Outlander GS45X. Manual - part 243

MFI SYSTEM <2.4L ENGINE>

TSB Revision

CIRCUIT DIAGRAMS

90-53

FUEL
PUMP
MODULE

ACCELERATOR PEDAL
POSITION SENSOR

HALL IC

HALL IC

(MAIN)

(SUB)

STARTING
SYSTEM

AIR
CONDITIONING
SYSTEM

CRUISE CONTROL
SYSTEM

·BRAKE WARNING LIGHT,
 FUEL WARNING LIGHT AND
 OIL PRESSURE WARNING LIGHT
·METER AND GAUGE

FUEL LEVEL
SENSOR
(MAIN)

FUEL TANK
TEMPERATURE
SENSOR

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE
Y : YELLOW     SB : SKY BLUE     BR : BROWN     O : ORANGE     GR : GRAY
R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

GROUND
(FRONT: LH)

MFI SYSTEM <2.4L ENGINE>

TSB Revision

CIRCUIT DIAGRAMS

90-54

MFI SYSTEM <2.4L ENGINE> (CONTINUED)

22

(FUSE     )

RELAY BOX

HEATED
OXYGEN
SENSOR

EVAPORATIVE
EMISSION
VENTILATION
SOLENOID

LINEAR
AIR-FUEL
RATIO
SENSOR

ENGINE
CONTROL
MODULE

GROUND
(FRONT: LH)

MFI SYSTEM <2.4L ENGINE>

TSB Revision

CIRCUIT DIAGRAMS

90-55

22

(FUSE     )

RELAY BOX

FUEL TANK
DIFFERENTIAL
PRESSURE SENSOR

MASS
AIRFLOW
SENSOR

MANIFOLD ABSOLUTE
PRESSURE SENSOR

MFI SYSTEM <2.4L ENGINE>

TSB Revision

CIRCUIT DIAGRAMS

90-56

MFI SYSTEM <2.4L ENGINE> (CONTINUED)

CAN DRIVE
CIRCUIT

CAN DRIVE
CIRCUIT

INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

ANALOG
INTERFACE
CIRCUIT

INTERFACE
CIRCUIT

DATA LINK
CONNECTOR

ETACS-ECU

ENGINE
CONTROL
MODULE

(FUSE     )

5

ETACS-ECU

JOINT
CONNECTOR
(CAN2)

JOINT
CONNECTOR
(CAN3)
