POWER DISTRIBUTION SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-25

·HEADLIGHT
·THEFT-ALARM
 SYSTEM

·HEADLIGHT
·THEFT-ALARM
 SYSTEM

·DAYTIME RUNNING
 LIGHT (DRL)
·HEADLIGHT
·THEFT-ALARM
 SYSTEM

·DAYTIME RUNNING
 LIGHT (DRL)
·HEADLIGHT
·THEFT-ALARM SYSTEM

·HEADLIGHT
·THEFT-ALARM
 SYSTEM

HEADLIGHT
RELAY
(HIGH)

HEADLIGHT
RELAY
(LOW)

HEADLIGHT
RELAY
(LOW)

REFER TO
HEADLIGHT CIRCUIT

HEADLIGHT
MANUAL
LEVELING
SYSTEM

<VEHICLES WITH DISCHARGE
TYPE HEADLIGHT>

<VEHICLES WITH HALOGEN
TYPE HEADLIGHT>

·HEADLIGHT
·HEADLIGHT MANUAL
 LEVELING SYSTEM
·THEFT-ALARM SYSTEM

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

POWER DISTRIBUTION SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-26

POWER DISTRIBUTION SYSTEM (CONTINUED)

FUSIBLE
LINK

36

RELAY BOX (ENGINE COMPARTMENT)

MFI
RELAY

·IGNITION SYSTEM
·IMMOBILIZER SYSTEM

·CRUISE CONTROL
 SYSTEM

·MFI SYSTEM

MFI SYSTEM
<3.0L ENGINE>

MFI SYSTEM

·CRUISE CONTROL SYSTEM
·IGNITION SYSTEM
·IMMOBILIZER SYSTEM
·MFI SYSTEM

POWER DISTRIBUTION SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-27

FUSIBLE
LINK

36

STARTING
SYSTEM

·AIR CONDITIONING
 SYSTEM
·COOLING SYSTEM

·ANTI-LOCK BRAKING
 SYSTEM (ABS)
·ANTI-LOCK BRAKING
 SYSTEM (ABS) AND
 ACTIVE STABILITY
 CONTROL SYSTEM (ASC)

<2.4L
ENGINE>

<3.0L ENGINE>

NOTE

: 2.4L ENGINE
: 3.0L ENGINE

WIRE COLOR CODE
B : BLACK     LG : LIGHT GREEN     G : GREEN     L : BLUE     W : WHITE     Y : YELLOW     SB : SKY BLUE
BR : BROWN     O : ORANGE     GR : GRAY     R : RED     P : PINK     V : VIOLET     PU : PURPLE     SI : SILVER

POWER DISTRIBUTION SYSTEM

TSB Revision

CIRCUIT DIAGRAMS

90-28

POWER DISTRIBUTION SYSTEM (CONTINUED)

ETACS-ECU

BLOWER
RELAY

ACC
RELAY 2

IG1
RELAY

IGNITION
SWITCH (IG1)

CENTRAL DOOR
LOCKING SYSTEM

ACCESSORY
SOCKET

AIR CONDITIONING
SYSTEM

·AUDIO SYSTEM
·MITSUBISHI MULTI-
 COMMUNICATION
 SYSTEM (MMCS)
·REAR SEAT
 ENTERTAINMENT SYSTEM
·REMOTE CONTROLLED
 MIRROR
·SPARE CONNECTOR
 (FOR REAR DISPLAY)

ACCESSORY
SOCKET

FUSIBLE
LINK

37

·ANTI-LOCK BRAKING SYSTEM (ABS)
 AND ACTIVE STABILITY CONTROL
 SYSTEM (ASC)
·BACKUP LIGHT
·INVECS-II 6A/T
·INVECS-III CVT
·MITSUBISHI MULTI- COMMUNICATION
 SYSTEM (MMCS)
·SPARE CONNECTOR
 (FOR NAVIGATION SYSTEM)
·SPARE CONNECTOR
 (FOR TRAILER LIGHTS)
·SUPPLEMENTAL RESTRAINT
 SYSTEM (SRS)

·AIR CONDITIONING SYSTEM
·ANTI-LOCK BRAKING SYSTEM (ABS)
·ANTI-LOCK BRAKING SYSTEM (ABS) AND
 ACTIVE STABILITY CONTROL SYSTEM (ASC)
·BRAKE WARNING LIGHT, FUEL WARNING LIGHT
 AND OIL PRESSURE WARNING LIGHT
·CENTRAL DOOR LOCKING SYSTEM
·CHARGING SYSTEM
·COOLING SYSTEM
·CRUISE CONTROL SYSTEM
·DAYTIME RUNNING LIGHT (DRL)
·DOME LIGHT, LUGGAGE COMPARTMENT LIGHT
 AND IGNITION KEY HOLE ILLUMINATION LIGHT
·DOOR AJAR WARNING TONE ALARM
·ELECTRONIC CONTROLLED AWD
·FOG LIGHT
·GLOVE BOX LIGHT
·HEADLIGHT
·HEATED DOOR MIRROR
·HEATED SEAT
·IGNITION KEY REMINDER TONE ALARM
 <VEHICLES WITH KOS>

·IMMOBILIZER SYSTEM
·INVECS-II 6A/T
·INVECS-III CVT
·KEYLESS OPERATING SYSTEM (KOS)
·METER AND GAUGE
·MFI SYSTEM
·PARKING BRAKE REMINDER TONE ALARM
·REAR WINDOW DEFOGGER
·REAR WIPER AND WASHER
·S-AWC
·SEAT BELT WARNING TONE ALARM
·SHIFT LOCK MECHANISM
·SUNROOF
·SUPPLEMENTAL RESTRAINT SYSTEM (SRS)
·TAILLIGHT, POSITION LIGHT, REAR SIDE MARKER
 LIGHT, LICENSE PLATE LIGHT AND LIGHTING
 MONITOR TONE ALARM
·THEFT-ALARM SYSTEM
·TIRE PRESSURE MONITORING SYSTEM (TPMS)
·TURN-SIGNAL LIGHT AND HAZARD WARNING LIGHT
·WINDSHIELD WIPER AND WASHER
