Mitsubishi Outlander GS45X. Manual - part 1750





SPECIAL TOOLS

TSB Revision

AUTOMATIC TRANSAXLE OVERHAUL

23D-7

SPECIAL TOOLS

M1233000601218

Transaxle

Tool

Tool number and name

Supersession

Application

MB992039
Slid hammer puller

MB992039-01

Remove of bearing outer
race

MB990590
Real axle shaft oil seal
remover

MB990211-01

Use with slid hammer
puller

MB992195
Spring compressor

Removal and installation
of low and reverse brake
snap ring

MB991550
Bearing outer race
installer

Installation of differential
taper roller bearing outer
race

MD998812
Installer cap

MIT304180-A or
General service tool

Use with installer and
installer adapter

MD998813
Installer-100

MIT304180-A or
General service tool

Use with installer cap and
installer adapter

MD998830
Installer adapter

MD998830-01

Installation of bearing
outer race

MB990590

A

B

SPECIAL TOOLS

TSB Revision

AUTOMATIC TRANSAXLE OVERHAUL

23D-8

MB991445
Bushing remover and
installer base

MB991445-01

Installation of differential
taper roller bearing outer
race <W6AJ>

MD998917
Bearing remover

General service tool or
MD998348-01

Removal and installation
of bearing

MB992197
Oil seal installer

Installation of differential
side oil seal

MB992075
Handle

Use with oil seal installer

MB992198
Oil seal installer

Installation of converter
housing oil seal

MB992196
Spring compressor

Removal and installation
of 2-6 brake piston snap
ring

MB990801
Rear axle bearing puller

Remove of tapered roller
bearing

MB990811
Side bearing puller cap

Use with rear axle bearing
puller

Tool

Tool number and name

Supersession

Application

MB990801

MB990811

SPECIAL TOOLS

TSB Revision

AUTOMATIC TRANSAXLE OVERHAUL

23D-9

MB990956
Needle bearing installer

Use with rear axle bearing
puller

MB990810
Side bearing puller

Remove of tapered roller
bearing

MD999566
Claw

Use with side bearing
puller

MD998761
Cam oil seal installer

Use with side bearing
puller

MD998826
Installer adapter

Installation of tapered
roller bearing <F6AJ>

MB991559
Cam oil seal installer
adapter

Installation of tapered
roller bearing <F6AJ>

MB992213
Bearing installer

Installation of tapered
roller bearing

MB992150
Oil seal installer

Installation of tapered
roller bearing

Tool

Tool number and name

Supersession

Application

MB990956

MB990810

MD998761

B991559

SPECIAL TOOLS

TSB Revision

AUTOMATIC TRANSAXLE OVERHAUL

23D-10

Transfer

Tool

Tool number and name

Supersession

Application

MD998812
Installer cap

MIT304180-A or
General service tool

Installation of reduction
gear bearing inner race
(converter housing side
and transaxle case side),
installation of differential
side bearing outer race
(converter housing side),
installation of differential
side bearing inner race
(converter housing side),
installation of reduction
pinion gear installation of
transfer oil seal

MB992154
Oil seal installer

Installation of transfer oil
seal

MD998777
Camshaft oil seal installer
adapter

Installation of transfer dust
seal

MD998713
 Camshaft oil seal installer

Installation of transfer dust
seal

MB992075
Handle

Installation of oil seal

MB992142
Oil seal installer

Installation of transfer oil
seal

MB990936
Oil seal installer

Installation of transfer oil
seal

MD998777

D998713
