PROPELLER SHAFT TSB Revision PROPELLER SHAFT 25-9 INSTALLATION SERVICE POINT . >>A<< PROPELLER SHAFT ASSEMBLY INSTAL- CAUTION • Do not damage the oil seal lip of the transfer. grease is stuck on the threads of the bolt and nut. • If the joint assembly is bent, it may be damaged when pinching the joint boots. . >>B<< FLANGE YOKE AND ELECTRONIC If the propeller shaft is reused, align the mating marks and Tightening torque: 54 ± 5 N⋅m (40 ± 3 ft-lb) INSPECTION M1251001100424 . PROPELLER SHAFT RUNOUT Limit • Front: 0.5 mm (0.02 inch) • Rear: 0.8 mm (0.03 inch) AC703266AB Oil seal Transfer AC703130AB |
