TROUBLESHOOTING
LOCAL INTERCONNECT NETWORK (LIN)
54B-9
STEP 4. Check the sunroof motor assembly.
Disconnect sunroof motor assembly connector, and
recheck whether diagnosis code No. U1515 is set.
(1) Connect all the relevant ECUs, and disconnect
sunroof motor assembly connector only.
(2) Erase the diagnosis code.
(3) Turn the ignition switch from "LOCK" (OFF) to
"ON" position.
(4) Check whether diagnosis code No. U1515 is set.
NOTE: If diagnosis code No. U1515 is not set,
diagnosis code No. U0169 is set because the
sunroof motor assembly is disconnected. This is
normal.
(5) Turn the ignition switch to the "LOCK" (OFF)
position.
Q: Is diagnosis code No. U1515 set?
YES :
Reconnect the sunroof motor assembly
connector, and go to Step 5.
NO :
Replace the sunroof motor assembly.
STEP 5. Check the lighting control sensor.
Disconnect lighting control sensor connector, and
recheck whether diagnosis code No. U1515 is set.
(1) Connect all the relevant ECUs, and disconnect
lighting control sensor connector only.
(2) Erase the diagnosis code.
(3) Turn the ignition switch from "LOCK" (OFF) to
"ON" position.
(4) Check whether diagnosis code No. U1515 is set.
NOTE: If diagnosis code No. U1515 is not set,
diagnosis code No. U0231 is set because the
sunroof motor assembly is disconnected. This is
normal.
(5) Turn the ignition switch to the "LOCK" (OFF)
position.
Q: Is diagnosis code No. U1515 set?
YES :
Reconnect the lighting control sensor, and
go to Step 6.
NO :
Replace the lighting control sensor.
STEP 6. Recheck for diagnosis code.
Check again if the diagnosis code is set to the
ETACS-ECU.
(1) Erase the diagnosis code.
(2) Turn the ignition switch from "LOCK" (OFF) to
"ON" position.
(3) Check whether diagnosis code No. U1515 is set.
(4) Turn the ignition switch to the "LOCK" (OFF)
position.
Q: Is the diagnosis code set?
YES :
Replace the ETACS-ECU.
NO :
The trouble can be an intermittent
malfunction (Refer to GROUP 00
− How to
Cope with Intermittent Malfunction ).
