ACB05048

2

Section A – A

3

AB

<Rear door trim>

1

5

6

3

9

A

A

Clip

NOTE
       : Clip positions



7

4

8

Rear door trim removal steps

<<

A

>>

1.

Inside handle cover cap

<<

B

>>

2.

Door trim cap

<<

C

>>

>>

A

<<

3.

Rear door trim

4.

Power window switch assembly

5.

Power window switch panel

6.

Power window switch

7.

Inside handle cover

8.

Door beltline weatherstrip inner

9.

Rear door pull handle bracket

TRIMS

INTERIOR

52A-12

REMOVAL SERVICE POINTS

<<A>> INSIDE HANDLE COVER CAP
REMOVAL

AC703869

Inside handle
cover cap

AB

Flat-tipped screwdriver

Insert a flat-tipped screwdriver as shown in the figure
to remove the inside handle cover cap.

<<B>> DOOR TRIM CAP

AC508380

Door trim cap

AB

Flat-tipped screwdriver

Insert a flat-tipped screwdriver as shown in the figure
to remove the door trim cap.

<<C>> FRONT/REAR DOOR TRIM
REMOVAL

AC303180

Inside lock cable

Inside handle cable

AB

Flat-tipped
screwdriver

Using a flat-tipped screwdriver as shown in the fig-
ure, remove the inside lock cable and the inside han-
dle cable, then remove the door trim.

TRIMS

INTERIOR

52A-13

INSTALLATION SERVICE POINTS

>>A<< FRONT DOOR/REAR DOOR TRIM
INSTALLATION

After the power window switch is installed or
replaced, perform learning of the power window
fully-closed position (Refer to GROUP 42A

− Door

Glass and Regulator ).

TRIMS

INTERIOR

52A-14

TAILGATE TRIM

REMOVAL AND INSTALLATION

M1521006500577

ACB05050 AB

3

5

4

B

B

Section A – A

Section E – E

Section B – B

Section C – C

Section D – D

4

5

A

A

4

C

C

5

1

E

E

D

D

Clip

Clip

Clip

Claw

Claw

Claw

Claw

C

C

D

D

Clip

Clip

5

2

5

Removal steps

1.

Tailgate pull handle

2.

Tailgate trim cap

3.

Tailgate trim

4.

Tailgate upper trim

5.

Tailgate opening side trim

TRIMS

INTERIOR

52A-15

Removal steps (Continued)
