INSTRUMENT PANEL ASSEMBLY

INTERIOR

52A-4

14. Instrument panel lower RH

<Vehicles with Knee air bag>

15. Instrument panel lower <Vehicles

without Knee air bag>

•.

Front floor console assembly (Refer
to ).

16. Centre lower box assembly
17. Bottom cover assembly

(passenger's side)

18. Glove box
19. Glove box assembly
20. Ornament panel assembly
•

Glove box lamp connector

•

Passenger’s (front) air bag module
connector connection (Refer to
GROUP 52B

− Passenger’s (front)

air bag module .)

•

Front pillar trim (Refer to ).

21. Instrument panel assembly

Removal steps (Continued)

INSTRUMENT PANEL ASSEMBLY

INTERIOR

52A-5

CLIP AND CLAW POSITIONS

ACB05997

AB

Section A – A

Section B – B

21

9

Section E – E

21

11

12

21

13

21

Section G – G

Section F – F

21

4

Section C – C

Section D – D

21

8

A

A

B

B

D

D

E

E

F

Clip

Clip

Clip

Clip

Clip

Clip

G

NOTE
(1)       :Clip positions
(2)       :Claw positions

C

C

F

G

13

21

Clip

NOTE: Each number in the illustration indicates a
part number.

INSTRUMENT PANEL ASSEMBLY

INTERIOR

52A-6

DISASSEMBLY AND ASSEMBLY

M1521001901164

ACB05040

3

2

4

AB

4

1

7

a

c

a

a

a

a

a

5

a

6

a

Disassembly steps

1.

Passenger’s (front) air bag module.

2.

Ventilation air distribution duct

3.

Defroster nozzle

4.

Instrument trim panel side air outlet

5.

Interior temperature sensor (Refer
to GROUP 55

− Interior

temperature sensor .)

6.

Aspirator hose

7.

Instrument panel

Disassembly steps (Continued)

FLOOR CONSOLE ASSEMBLY

INTERIOR

52A-7

FLOOR CONSOLE ASSEMBLY

FRONT FLOOR CONSOLE ASSEMBLY

REMOVAL AND INSTALLATION

M1521005200885

ACB05038

1

1

2

4

11

12

13

AB

A

A

 Section A – A

1

Clip

3

9

7

8

6

5

10

2.5 ± 0.5 N·m

11 ± 2 N·m

2.5 ± 0.5 N·m

2.5 ± 0.5 N·m

2.5 ± 0.5 N·m

2.5 ± 0.5 N·m

11 ± 2 N·m

11 ± 2 N·m

11 ± 2 N·m

5.0 ± 1.0 N·m

5.0 ± 1.0 N·m

NOTE
(1)       :Clip positions
(2)       :Claw positions

Removal steps

•

Centre lower panel assembly
(Refer to ).

1.

Floor console side cover

2.

Floor console bracket front

•

Rear floor console assembly (Refer
to ).

•

Selector lever knob (Refer to
GROUP 23A

− Transmission

Control )

3.

Floor console parking brake lever
cover

•

4WD switch connector connection

Removal steps (Continued)
