SPECIAL TOOLS

ENGINE MECHANICAL

11A-3

SPECIAL TOOLS

M1112000603212

Tool

Number

Name

Use

B992080

a

b

MB992080
a: MB992081
b: MB992082

Belt tension meter set
a: Belt tension meter
b: Microphone assembly

Alternator and others belt
tension check

ACB05421

MB992745

MB992746

MB992744

MB992747

MB992748

a

b

c

d

e

DO NOT USE

AB

a. MB992744
b. MB992745
c. MB992746
d. MB992747
e. MB992748

a. Vehicle communication

interface-Lite
(V.C.I.-Lite)

b. V.C.I.-Lite main

harness A (for vehicles
with CAN
communication)

c. V.C.I.-Lite main

harness B (for vehicles
without CAN
communication)

d. V.C.I.-Lite USB cable

short

e. V.C.I.-Lite USB cable

long

• Checking the ignition timing

• Checking the idle speed

MB991910

MB991826

MB991955

MB991911

MB991824

MB991827

MB991825

a

b

c

d

e

f

DO NOT USE

SPECIAL TOOLS

ENGINE MECHANICAL

11A-4

MB991955

a: MB991824
b: MB991827
c: MB991910
d: MB991911
e: MB991825
f: MB991826

M.U.T.-III sub assembly

a: Vehicle communication

interface (V. C. I.)

b: M.U.T.-III USB cable
c: M.U.T.-III main harness

A (Vehicles with CAN
communication system)

d: M.U.T.-III main harness

B (Vehicles without
CAN communication
system)

e: M.U.T.-III adapter

harness

f: M.U.T.-III trigger

harness

CAUTION

For vehicles with CAN
communication, use
M.U.T.-III main harness A to
send simulated vehicle
speed. If you connect
M.U.T.-III main harness B
instead, the CAN
communication does not
function correctly.

• Checking the ignition timing

• Checking the idle speed

B990767

MB990767

Front hub and flange yoke
holder

Holding the crankshaft pulley

D998719

MD998719

Pin

Tool

Number

Name

Use

B992103

SPECIAL TOOLS

ENGINE MECHANICAL

11A-5

MB992103

Chain tension release bar

Camshaft and camshaft
sprocket assembly (exhaust
side) removal

MD998772

MD998772

Valve spring compressor

Valve spring compression

B992090

MB992090

Retainer holder
attachment

MB992089

Retainer holder C

MB992085

Valve stem seal pliers

Valve stem seal removal

MD998737

Valve stem seal installer

Valve stem seal press-fitting

D998727

MD998727

Oil pan FIPG cutter

Engine oil pan removal

MB991883

MB991883

Flywheel stopper

Supporting the drive plate

Tool

Number

Name

Use

SPECIAL TOOLS

ENGINE MECHANICAL

11A-6

MD998718

Crankshaft rear oil seal
installer

Press-fitting the crankshaft
rear oil seal

MB991448

Bush remover and installer
base

Press-fitting the crankshaft
front oil seal

MB991614

MB991614

Angle gauge

Balancer shaft and oil pump
module bolt installation

Tool

Number

Name

Use
