DUCT
HEATER, AIR CONDITIONER AND VENTILATION
55-16
DUCT
M2551001300842
The following air outlet system has been adopted to
improve comfort.
• The FACE vents at the driver's side is located so
that air is directed to the driver's face rather than
hands. This improves comfort.
• A rear heater duct is fitted in order to improve
comfort.
ACB05540
ACB05540
To front door window
(Side defroster)
Side ventilator
To windshield (Defroster)
To front door window
(Side defroster)
To passenger seat footwell
To rear seat footwell
To rear seat footwell
Side ventilator
AC
Centre ventilator
To driver seat footwell
