Mitsubishi Outlander (2013+). Manual - part 199

TRIMS

INTERIOR

52A-8

• A seat belt warning lamp has been included on

the combination meter to encourage the driver to
fasten the seat belt when the belt is not con-
nected.

• A seat belt warning lamp has been included on

the centre panel to encourage the passenger to
fasten the seat belt when the belt is not con-
nected.

<Second seat belt>

• 3-point seat belt with ELR has been installed.

• The seat belt tongue can be inserted into the

buckle easily as the self-standing buckles are
used for all seating positions.

TRIMS

INTERIOR TRIM

M2520012000883

• The interior trim is a full trim to improve quality.

• The collision energy absorbing structure that is

integrated with a trim has been adopted to the pil-
lar trim. With the structure that reduces head inju-
ries upon the secondary impact against the cabin
during a collision, the safety has been improved.

• Material codes are shown on trim to facilitate

recycling.

ACB05046AB

Cowl side trim

Front pillar trim

Upper centre pillar trim

Quarter trim upper

Rear end trim

Lower quarter trim

Rear scuff plate

Lower centre pillar trim

Front scuff plate

Quarter trim
cover

Downloaded from

www.Manualslib.com



manuals search engine



TRIMS

INTERIOR

52A-9

DOOR TRIM

M2520012300828

The door trims offer the following features.

• Break-proof resin material has been used for trim

panels, improving safety.

• Bottle holders which can store a 500-ml plastic

bottle have been installed to the front door trim
and rear door trim to improve convenience. Also,
the bottle holding capability has been improved to
accommodate bottles with shapes that are diffi-
cult to keep upright.

• Door pockets have been installed to the front and

rear door trim panels. The front door pockets
have a large capacity that can hold A4-size
maps.

• For the armrests, the energy absorbing structure

has been adopted which reduces the mid section
injuries to passengers by collapsing. Also, with
one-piece forming of the cloth with a soft layer
added, the quality has been improved.

• Soft pads are attached to the front door trim

upper panels.

• Two types of decoration panels on the instrument

panel passenger side and the front door trim pro-
vide a continuous appearance. A luxurious but
moderate wood decoration panel is available for
high grade models. Carbon silver decoration
panel underlining sporty appearance quality

• To prevent your fingers from being slipped off

during door closing, the pull handle recess has
been modified.

• To accommodate various types of bottles, the

bottle holders are larger but clear in design.

ACB05049

<Rear door trim>

<Front door trim>

AB

Armrest

Bottle holder

Door pocket

Armrest

Door pocket

Downloaded from

www.Manualslib.com



manuals search engine



LUGGAGE ROOM

INTERIOR

52A-10

LUGGAGE ROOM

M2520013000422

• The rear side box has been equipped to improve

usability.

• Luggage floor box has been equipped to the lug-

gage room floor to improve usability.

• Adding a luggage floor box allows virtually flat

flooring from the second seat to the rear end. The
customer can load and unload even long object
much easier.

• The luggage floor box is approx. 100 cm long,

approx. 100 cm wide and approx. 15 cm deep
(total capacity: approx. 68 litre). It can accommo-
date the tonneau cover or a flat tyre repair kit
tidily by partitions.

• The luggage floor board is divided into two pieces

via hinges. This structure allows the driver to gain
access to the luggage floor box by opening a
respective separate lid only even when large
object is being stowed.

• The rear side box between the quarter trim and

the luggage floor box is useful for stowing a small
object. The customer can accommodate soft
objects such as plastic bags in the rear side box.
Furthermore, the customer can take out them
easily as the box has no lid.

ACC00099AB

Luggage floor board

Tonneau cover

Luggage floor box

Luggage floor board

Rear side box

Downloaded from

www.Manualslib.com



manuals search engine



HEADLINING

INTERIOR

52A-11

HEADLINING

M2520014000674

Interior design with safe material has been adopted,
achieving more safe and comfortable interior.

• Headlining which absorbs and dissolves chemi-

cal substances has been adopted. This headlin-
ing efficiently absorbs and dissolves a smoking

smell, a life-smell, and formaldehyde

*

.

• Chemical substances such as formaldehyde and

organic solvent generated from the interior parts
have been minimised by the refined material and
method, improving amenity.

NOTE:

*

: Clear and colourless, toxic, irritating odour

ACB05042AB

Headlining
