TYPE A (PROJECTED DIMENSIONS)

BODY DIMENSIONS

2-6

8

Centre of front floor sidemember front positioning hole

Round

16

13

Centre of front axle crossmember mounting hole

Round

15.5

14

Centre of trailing arm assembly mounting hole

Round

14

15

Centre of trailing arm assembly mounting hole

Round

14

16

Centre of rear suspension crossmember mounting hole

Round

15

17

Centre of rear suspension crossmember mounting hole

Round

15

18

Centre of rear shock absorber assembly mounting hole

Round

64

19

Centre of front strut assembly mounting hole

Round

92.6

No.

Standard measurement point

Hole shape

Size mm

ABB00764

AB

Standard line

NOTE: The assumed standard line is established 100 mm below the measurement point No.4.

15

14

17

16

13

4

3

8

18

19

294

100

105

222

284

354

462

782

162

510

217

539

570

820

1066

1258

1122

A

B

Vehicle centre

Vehicle centre

A

B

3˚06´

6˚54´

6˚30´

0˚

Unit: mm

ABB00745

AB

3

ABB00746

AB

4

13

4, 13

ABB00942

AB

8

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-7

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

UNDER BODY

M4020005002606

ABB00750

AB

15

14

14, 15

ABB00751

AB

18

17

16

16, 17, 18

ABB00744

AB

19

ABB00765AB

Unit: mm

1

12

6

11

5

10

4

9

3

8

2

7

976

1262

960

1022

910

1056

875

1079

222

894

894

877

719

542

546

567

644

378

350

377

487

460

399

582

702

856

965

774

235

ABB00766

AB

1

12

6

11

5

10

4

9

3

8

2

7

996

1185

1415

765

1081

643

1046

565

1138

960

1273

1230

1127

1356

1225

1418

1027

1125

704

Unit: mm

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-8

No.

Standard measurement point

Hole shape

Size mm

1

Centre of front end side panel mounting hole

Round

16

2

Centre of front sidemember inner positioning hole

Round

25

3

Centre of front axle crossmember mounting hole

Round

15.5

4

Centre of front sidemember rear water draining hole

Round

16

5

Centre of propeller shaft assembly mounting hole (left side)

Round

11

6

Centre of propeller shaft assembly mounting hole (right side)

Round

11

7

Centre of front floor sidemember front positioning hole

Round

16

8

Centre of front floor sidemember front positioning hole

Round

16

9

Centre of rear floor sidemember lower positioning hole

Oblong

33.9

×18

10

Centre of rear suspension bracket front water draining hole

Round

16

11

Centre of rear floor sidemember lower positioning hole

Round

25

12

Centre of trailer hitch mounting hole

Round

11

ABB00743

AB

2

1

1, 2

ABB00745

AB

3

ABB00943

AB

4

ABB00747

AB

5

6

5, 6

ABB00748

AB

7

ABB00749

AB

9

8

8, 9

ABB00940

AB

10

11

10, 11

ABB00752

AB

12

TYPE B (ACTUAL-MEASUREMENT DIMENSIONS)

BODY DIMENSIONS

2-9

SUSPENSION INSTALLATION
DIMENSIONS

M4020013002474

ABB00767

AB

Unit: mm

15

14

17

16

13

4

3

8

910

1288

875

1092

894

1000

886

903

322

226

546

590

262

446

727

614

841

295

707

98

ABB00768

AB

15

14

17

16

13

4

3

8

954

1046

909

1236

1265

1173

1151

1219

1077

1300

1050

Unit: mm

No.

Standard measurement point

Hole shape

Size mm

3

Centre of front axle crossmember mounting hole

Round

15.5

4

Centre of front sidemember rear water draining hole

Round

16

8

Centre of front floor sidemember front positioning hole

Round

16

13

Centre of front axle crossmember mounting hole

Round

15.5

14

Centre of trailing arm assembly mounting hole

Round

14

15

Centre of trailing arm assembly mounting hole

Round

14

16

Centre of rear suspension crossmember mounting hole

Round

15

17

Centre of rear suspension crossmember mounting hole

Round

15
