FOG LAMP

CHASSIS ELECTRICAL

54A-83

FRONT FOG LAMP RELAY CHECK

AC309319

1

4

3

2

AB

Front fog lamp relay

Battery voltage

Tester
connection

Specified
condition

Not supplied

1

−

 4

Open circuit

•

Connect
terminal 3 to
the positive
battery terminal

•

Connect
terminal 2 to
the negative
battery terminal

1

−

 4

Less than 2
ohms

REAR FOG LAMP

CHASSIS ELECTRICAL

54A-84

REAR FOG LAMP

TROUBLESHOOTING

M1542000701452

If the rear fog lamp switch is turned ON when the
headlamp or the front fog lamp is turned ON, the rear
fog lamp is switched ON and OFF alternatively.
If the headlamp and the front fog lamp, the rear fog
lamp is turned OFF at the same time.

The fog lamps are controlled by the Smart Wiring
System (SWS). For Troubleshooting, refer to
respective Groups below.

•

Not using SWS monitor: GROUP 54B, SWS
Troubleshooting

P.54B-41

.

•

Using SWS monitor: GROUP 54C, SWS
Troubleshooting

P.54C-25

.

SPECIAL TOOL

M1542000601046

REAR FOG LAMP

REMOVAL AND INSTALLATION

M1542009800088

Tool

Number

Name

Use

MB990784

Ornament remover Removal of instrument panel

driver’s side garnish, meter bezel
and fog lamp switch

MB990784

AC300487

1

2

4

3

1.5 ± 0.5 N·m

6

7

8

9

AB

5

Vehicles with
front fog lamp

Vehicles without
front fog lamp

REAR FOG LAMP

CHASSIS ELECTRICAL

54A-85

INSPECTION

M1542007700052

REAR FOG LAMP SWITCH CONTINUITY
CHECK

REAR FOG LAMP RELAY CHECK

Rear fog lamp switch removal
steps

1. Instrument panel driver’s side

garnish (Refer to GROUP 52A,
Instrument panel

P.52A-2

<LHD> or

P.52A-8

<RHD>.)

2. Meter bezel (Refer to GROUP 52A,

Instrument panel

P.52A-2

<LHD> or

P.52A-8

<RHD>.)

3. Fog lamp switch bracket
4. Fog lamp switch (front fog lamp

switch and rear fog lamp switch)

5. Fog lamp switch (rear fog lamp

switch)
Rear fog lamp removal steps

•

Rear bumper (Refer to GROUP 51,
Rear bumper

P.51-6

.)

6. Rear fog lamp assembly
7. Rear fog lamp body and lens
8. Socket
9. Bulb

Switch position Tester

connection

Specified
condition

Pressed

1

−

 2

Less than 2
ohms

Released

1

−

 2

Open circuit

AC201409

6

2

1

3 4 5

AB

Battery voltage

Tester
connection

Specified
condition

Not supplied

1

−

 4

Open circuit

•

Connect
terminal 3 to
the positive
battery terminal

•

Connect
terminal 2 to
the negative
battery terminal

1

−

 4

Less than 2
ohms

AC210598

1

4

3

2

1 2

4

3

AB

Rear fog lamp relay

Junction block

SIDE TURN SIGNAL LAMP

CHASSIS ELECTRICAL

54A-86

SIDE TURN SIGNAL LAMP

SPECIAL TOOL

M1542000601057

SIDE TURN SIGNAL LAMP

REMOVAL AND INSTALLATION

M1542003300171

Tool

Number

Name

Use

MB990784

Ornament remover Removal of side turn-signal lamp

MB990784

AC203309 AD

1

2

3

4

Removal steps

<<A>> >>A<<

1.

Side turn-signal lamp assembly

2.

Side turn-signal lamp

3.

Bulb

4.

Socket
