DOOR TRIM
INTERIOR
52A-23
REMOVAL SERVICE POINT
<<A>> DOOR INSIDE HANDLE COVER REMOVAL
1. Insert a flat-tipped screwdriver into the back end
of the tapping screw cap of the door inside handle
cover.
2. Try the screwdriver in the direction of the arrow.
Remove the cap, then remove the tapping screw.
3. Insert the special tool ornament remover
(MB990784) in the gap between the door inside
handle cover and door inside handle in the area
shown. Then remove the thumb clamp of the door
inside handle cover and door inside handle.
4. Insert a special tool from the back end of the door
inside handle cover to lift it in the direction of the
arrow. Then remove the door inside handle cover.
AC100003AF
Tapping screw cap
AC100004
A
A
B
B
Special tool
insertion
position
Door inside
handle cover
MB990784
Claw
Door trim
Section A – A
Section B – B
Door inside
handle cover
Claw
Claw
Door inside
handle cover
AD
