TROUBLESHOOTING

ANTI-SKID BRAKING SYSTEM (ABS)

35B-47

COMMENT ON TROUBLE SYMPTOM
Possible causes include the combination meter
power circuit, disconnected earth circuit, dead lamp
bulb, or short circuited ABS warning lamp.

PROBABLE CAUSES
The most likely causes for this case are:

•

Blown fuse

•

Damaged wiring harness or connector

•

Burnt out ABS warning lamp bulb

•

Combination meter defect

•

Malfunction of the hydraulic unit (integrated with
ABS-ECU)

DIAGNOSIS

STEP 1. Check the ABS warning lamp circuit at
ABS-ECU connector B-03.

(1) Disconnect ABS-ECU connector B-03.
(2) Turn the ignition switch to the "ON" position.

Q: Does the ABS warning lamp illuminate?

YES :

To check and reproduce the state of

malfunction replace the hydraulic unit
(integrated with ABS-ECU). Then go to Step
7. If the malfunction is not reproduced, an
intermittent malfunction is suspected. Refer
to GROUP 00, How to Use
Troubleshooting/Inspection Service Points

−



How to Cope with Intermittent Malfunction

P.00-6

.

NO :

Go to Step 2.

AC301441AB

Connector: B-03

B-03 (GR)

Harness side

TROUBLESHOOTING

ANTI-SKID BRAKING SYSTEM (ABS)

35B-48

STEP 3. Voltage measurement at the combination
meter connector C-04.

(1) Disconnect connector C-04, and check at the

harness side.

(2) Turn the ignition switch to the "ON" position.

(3) Measure the voltage between terminal 42 and

earth.

OK: System voltage

Q: Is the check result normal?

YES : .

Go to Step 5.

NO : .

Go to Step 4.

AC308716

AS

C-04

Connector: C-04
<LHD>

Harness side

AC308769

AV

C-04

Connector: C-04
<RHD>

Harness side

41

52

40

51

39

50

38

49

37

48

36

47

35

46

34

45

33

44

32

43

31

42

AC301541FZ

Connector C-04
(Junction block side)

<LHD>

AC301541GA

Connector C-04
(Junction block side)

<RHD>

41

52

40

51

39

50

38

49

37

48

36

47

35

46

34

45

33

44

32

43

31

42

TROUBLESHOOTING

ANTI-SKID BRAKING SYSTEM (ABS)

35B-49

STEP 4. Check the harness wire between
junction block connector C-203 terminal 6 and
combination meter C-04 terminal 42.

NOTE: After inspecting junction block connectors
C-203 and C-205, and combination meter connector
C-04, inspect the wire. If any of these connectors is
damaged, repair or replace it. Then go to Step 7.

Q: Is the harness wire between junction block

connector C-203 terminal 6 and combination meter
C-04 terminal 42 damaged?

YES :

Repair the harness wire and go to Step 7.

NO :

This malfunction is intermittent. Refer to
GROUP 00, How to Use
Troubleshooting/Inspection Service Points

−



How to Cope With Intermittent Malfunction

P.00-6

.

AC308716

AS

C-04

Connector: C-04
<LHD>

Harness side

AC308721

C-203

AO

C-205

Connectors: C-203, C-205
<LHD>

C-203

Harness side

C-205

Harness side

4

6 5

3

2

1

21

7

16 15

17

18

20 19

1

2

3

4

5

6

23 22

24

25

28

26

27

9

8

10

11

14

12

13

AC308769

AV

C-04

Connector: C-04
<RHD>

Harness side

41

52

40

51

39

50

38

49

37

48

36

47

35

46

34

45

33

44

32

43

31

42

AC308773

C-203

AP

C-205

Connectors: C-203, C-205
<RHD>

C-203

Harness side

C-205

Harness side

4

6 5

3

2

1

21

7

16 15

17

18

20 19

1

2

3

4

5

6

23 22

24

25

28

26

27

9

8

10

11

14

12

13

TROUBLESHOOTING

ANTI-SKID BRAKING SYSTEM (ABS)

35B-50

STEP 5. Check the harness wire between the
combination meter connector C-05 terminal 12
and earth (No.6).

Q: Is the harness wire between combination meter

connector C-05 terminal 12 and earth (No.6)
damaged?

YES :

Repair the harness wire and go to Step 7.

NO :

Go to Step 6.

STEP 6. Check the harness wire between the
combination meter connector C-05 terminal 18
and ABS-ECU connector B-03 terminal 12.

AC308716

AT

C-05 (L)

Connector: C-05
<LHD>

Harness side

G

G

22

11

5

16

19

20

21

17

18

8

10 9

7 6

13

1514

12

2

4 3

1

AC308769

AW

C-05 (L)

Connector: C-05

<RHD>

Harness side

11

22

10

21

9

20

8

19

7

18

6

17

5

16

4

15

3

14

2

13

1

12

AC208084AE

Junction
block

Earth (No.6)

AC308716

AT

C-05 (L)

Connector: C-05
<LHD>

Harness side

G

G

22

11

5

16

19

20

21

17

18

8

10 9

7 6

13

1514

12

2

4 3

1

AC308769

AW

C-05 (L)

Connector: C-05

<RHD>

Harness side

11

22

10

21

9

20

8

19

7

18

6

17

5

16

4

15

3

14

2

13

1

12

AC301441AB

Connector: B-03

B-03 (GR)

Harness side
