SPECIFICATIONS TSB Revision AUTOMATIC TRANSMISSION 23A-465 SERVICE SPECIFICATIONS M1231100300129 Transmission control 24 N ⋅m (18 ft-lb) Cable bracket mounting bolt 12 N ⋅m (106 in-lb) Cable end bracket mounting bolt 24 N ⋅m (18 ft-lb) Indicator assembly mounting screw 1.5 N ⋅m (13 in-lb) Key interlock cable mounting nut 12 N ⋅m (106 in-lb) Retainer mounting nut 5 N ⋅m (44 in-lb) Selector lever assembly mounting bolt 12 N ⋅m (106 in-lb) Selector lever to bracket mounting bolt 12 N ⋅m (106 in-lb) Shift lock cable mounting nut 12 N ⋅m (106 in-lb) Stopper plate mounting bolt 19 N ⋅m (15 ft-lb) Shift knob attaching screw 2.0 N ⋅m (18 in-lb) Transmission oil cooler 39 − 44 N⋅m (29 − 32 ft-lb) ITEM SPECIFICATION ITEM STANDARD VALUE Clearance between the sleeve and lever assembly end mm (in) 16.0 − 16.8 (0.62 − 0.66) Clearance between the detent plate and pin mm (in) 0.1 − 0.9 mm (0.004 − 0.040) Line pressure MPa (psi) 0.98 − 1.05 (142 − 152) Transmission fluid temperature sensor k Ω at 0°C (32°F) 16.7 − 20.5 at 20 °C (68°F) 7.3 − 8.9 at 40 °C (104°F) 3.4 − 4.2 at 60 °C (140°F) 1.9 − 2.2 at 80 °C (176°F) 1.0 − 1.2 at 100 °C (212°F) 0.57 − 0.69 Resistance of torque converter clutch control solenoid valve coil °C (68°F)] Ω 2.7 − 3.4 Resistance of low-reverse solenoid valve coil [at 20 °C (68°F)] Ω 2.7 − 3.4 Resistance of second solenoid valve coil [at 20 °C (68°F)] Ω 2.7 − 3.4 Resistance of underdrive solenoid valve coil [at 20 °C (68°F)] Ω 2.7 − 3.4 Resistance of overdrive solenoid valve coil [at 20 °C (68°F)] Ω 2.7 − 3.4 Stall speed r/min 2,300 − 2,900 |
