FRONT BUMPER ASSEMBLY
TSB Revision
EXTERIOR
51-3
DISASSEMBLY AND ASSEMBLY
M1511001600567
AC003745 AB
3
5
4
8
7
6
2
1
2
0.7 N·m
6.2 in-lb
2.5 N·m
22 in-lb
7
6
0.7 N·m
6.2 in-lb
3
2.5 N·m
22 in-lb
DISASSEMBLY STEPS
1. FRONT BUMPER BEAM ASSEMBLY
2. FRONT BUMPER SIDE
REINFORCEMENT
3. FRONT BUMPER SIDE EXTENSION
4. FRONT BUMPER GRILL
<VEHICLES WITH FOG LIGHT>
5. FRONT BUMPER GRILL
<VEHICLES WITHOUT FOG LIGHT>
6. FOG LIGHT BRACKET <VEHICLES
WITH FOG LIGHT>
7. FOG LIGHT <VEHICLES WITH FOG
LIGHT>
8. FRONT BUMPER FACE
DISASSEMBLY STEPS (Continued)
