VEHICLE IDENTIFICATION

TSB Revision

GENERAL <BODY AND CHASSIS>

00-19

CHASSIS NUMBER

.

STAMPING LOCATION
The chassis number is stamped on the side of the frame near
the right rear wheel.

CHASSIS NUMBER CODE CHART

VEHICLE SAFETY CERTIFICATION LABEL

The vehicle safety certification label is attached to the face of
the left door sill.
This label indicates the month and year of manufacture, Gross
Vehicle Weight Rating (GVWR), front and rear Gross Vehicle
Weight Rating (GAWR), and Vehicle Identification Number
(VIN).

ENGINE MODEL STAMPING

The engine model is stamped on the cylinder block.
These engine model numbers are as shown as follows.

The engine serial number is stamped near the engine model
number.

AC003348

CHASSIS
NUMBER
CODE

CONTENT

K8601P000001 K860: Vehicle

line

K890, K990; MONTERO SPORT (3.5L Engine)

1P000001: Refer to 10th thru 17th digits of Vehicle Identification Number (vin) plate

ACX00876AB

ENGINE MODEL

ENGINE DISPLACEMENT

6G74

3.5L

ACX00877AD

VEHICLE IDENTIFICATION

TSB Revision

GENERAL <BODY AND CHASSIS>

00-20

THEFT PROTECTION

In order to protect against theft, a Vehicle Identification Number
(VIN) is attached as a plate or label to the following major parts
of the engine and transmission, as well as main outer panels:
Engine cylinder block, Transmission housing. Fender, Doors,
Liftgate, Quarter panel, Hook, Bumpers.
In addition, a theft-protection label is attached to replacement
parts for the body outer panel main components, and the same
data are stamped into replacement parts for the engine and the
transmission.

CAUTION

Cautions regarding panel repairs:

• When repainting original parts, do so after first masking

the theft-protection label. After painting, be sure to peel
off the masking tape.

• The theft-protection label for replacement parts is cov-

ered by masking tape, so such parts can be painted as
is. The masking tape should be removed after painting
is finished.

• The theft-protection label should not be removed from

original parts or replacement parts.

ACX00878 AB

THEFT PROTECTION PLATE (VIN PLATE)

FOR ENGINE

FOR TRANSMISSION

THEFT PROTECTION LABEL

FOR MAIN OUTER PANELS

[FOR ORIGINAL PARTS]

[FOR REPLACEMENT PARTS]

VEHICLE IDENTIFICATION

TSB Revision

GENERAL <BODY AND CHASSIS>

00-21

LOCATIONS

AC103838

LABEL AREA (A: FOR ORIGINAL EQUIPMENT PARTS, B: FOR REPLACEMENT PARTS)

ENGINE

A

B

ENGINE UNDERSEIDE

AUTOMATIC TRANSMISSION
<R4A51, V4A51>

B

A

UPPER SIDE

RIGHT SIDE

FENDER

FRONT DOOR

QUARTER PANEL

REAR DOOR

A

B

A

B

A

B

A

B

THE ILLUSTRATION INDICATES LEFT OUTER SIDE.
RIGHT SIDE IS SYMMETRICALLY OPPOSITE.

THE ILLUSTRATION INDICATES LEFT OUTER SIDE.
RIGHT SIDE IS SYMMETRICALLY OPPOSITE.

THE ILLUSTRATION INDICATES RIGHT OUTER SIDE.
LEFT SIDE IS SYMMETRICALLY OPPOSITE.

THE ILLUSTRATION INDICATES RIGHT OUTER SIDE.
LEFT SIDE IS SYMMETRICALLY OPPOSITE.

AB

VEHICLE IDENTIFICATION

TSB Revision

GENERAL <BODY AND CHASSIS>

00-22

AC003351AC

LABEL AREA (A: FOR ORIGINAL EQUIPMENT PARTS, B: FOR REPLACEMENT PARTS)

HOOD

LIFTGATE

FRONT BUMPER

REAR BUMPER

A

B

A

B

A

B

A

B
