Mitsubishi Montero Sport (2004+). Manual - part 13

RELAY

TSB Revision

COMPONENT LOCATIONS

70-7

AC202133 AB

C

DRL UPPER
RELAY

DRL LOWER
RELAY

CONDENSER FAN
MOTOR RELAY

A/C COMPRESSOR
RELAY

AC002585AC

TURN-SIGNAL
AND HAZARD
WARNING
FLASHER UNIT

JUNCTION
BLOCK

D

AC002586

E

AB

ACCESSORY
SOCKET
RELAY

REAR
HEATER
RELAY

POWER
WINDOW
RELAY

REAR INTERMITTENT
WIPER RELAY

RELAY BOX IN
PASSENGER
COMPARTMENT

AC002587AB

F

INTERMITTENT
WIPER RELAY

AC002588

G

AB

THEFT-
ALARM
HORN
RELAY

DEFOGGER
RELAY

HAZARD
WARNING
RELAY

AC002589

H

AB

FUEL PUMP
RELAY

MULTIPORT FUEL
INJECTION RELAY

AC002590AB

A/T CONTROL
RELAY

H

SENSOR

TSB Revision

COMPONENT LOCATIONS

70-8

SENSOR

M1701000600437

NAME

SYMBOL NAME

SYMBOL

Air thermo sensor <A/C>

K

Left bank heated oxygen sensor
(rear)

S

Ambient temperature sensor
<Compass and temperature display>

J

Manifold absolute pressure sensor

E

Camshaft position sensor

Q

Output shaft speed sensor

P

Crankshaft position sensor

G

Rear light sensor

O

Engine coolant temperature sensor

D

Right bank heated oxygen sensor
(front)

C

Fuel tank differential pressure sensor I

Right bank heated oxygen sensor
(rear)

R

Fuel temperature sensor

I

Throttle position sensor

B

Front impact sensor <SRS>

H

Transmission fluid temperature
sensor

M

Front light sensor

O

Vehicle speed sensor

P

G-sensor <4WD-ABS>

L

Volume air flow sensor

A

Input shaft speed sensor

P

Wheel speed sensor (front) <ABS>

N

Left bank heated oxygen sensor
(front)

F

Wheel speed sensor (rear) <ABS>

T

AC002556 AG

A

B

D

E

F

C

K

L

G

H

J

H

Q

*

SENSOR

TSB Revision

COMPONENT LOCATIONS

70-9

NOTE: The * symbols indicate equipped at both sides.

AC002591AD

M

N

O

P

T

R

S

N

T

I

*

AC002592

A

AB

VOLUME AIR FLOW SENSOR

AC002593AB

B

THROTTLE
POSITION SENSOR

AC201602

C

AB

RIGHT BANK
HEATED OXYGEN
SENSOR (FRONT)

RIGHT BANK
HEATED OXYGEN
SENSOR (FRONT)
CONNECTOR

AC002595AB

D

ENGINE COOLANT
TEMPERATURE SENSOR

AC002596AE

E

MANIFOLD
ABSOLUTE
PRESSURE
SENSOR

SENSOR

TSB Revision

COMPONENT LOCATIONS

70-10

AC201603 AB

EXHAUST
MANIFOLD (LH)

LEFT BANK HEATED
OXYGEN SENSOR (FRONT)

F

LEFT BANK
HEATED OXYGEN
SENSOR (FRONT)
CONNECTOR

AC201604 AB

CRANKSHAFT
SPROCKET

CRANKSHAFT
POSITION
SENSOR

G

CRANKSHAFT
POSITION SENSOR
CONNECTOR

AC002598 AE

FENDER SHIELD
PANEL

FRONT IMPACT
SENSOR

H

AC102879AD

FUEL TANK DIFFERENTIAL
PRESSURE SENSOR

FUEL
TEMPERATURE
SENSOR

I

AC002601

J

AE

AMBIENT
TEMPERATURE
SENSOR

AC002602AB

K

AIR THERMO
SENSOR
