Mitsubishi Montero Sport (2004+). Manual - part 12

INSPECTION TERMINAL

TSB Revision

COMPONENT LOCATIONS

70-3

INSPECTION TERMINAL

M1701000200268

AC002562

FUSE
(No.20)

AC

D

FUSES
(No.18,19)

RELAY BOX IN
PASSENGER
COMPARTMENT

NAME

SYMBOL NAME

SYMBOL

Data link connector (1), (2)

B

Engine speed detection connector

A

AC002556AC

A

B

AC002563 AF

ENGINE SPEED
DETECTION
CONNECTOR

WINDSHIELD
WIPER MOTOR

A

AC002564AB

B

DATA LINK CONNECTOR (1)

DATA LINK CONNECTOR (2)

GROUNDING

TSB Revision

COMPONENT LOCATIONS

70-4

GROUNDING

M1701000300403

NOTE: 1 to 12 numbers correspond to the body ground point numbers in CIRCUIT DIAGRAMS.

AC002723AB

1

2

4

5

6

7

11

12

3

8

9

10

AC002565AB

1

AC002566AB

2

AC002567AB

3

AC002568

4

AB

CENTER
UNDER COVER

GROUNDING

TSB Revision

COMPONENT LOCATIONS

70-5

AC002569AB

5

AC002570AC

REAR SEAT BELT (RH)

6

AC002571

7

AB

LIFTGATE

AC002572 AC

8

REAR SEAT BELT (LH)

AC002573AB

9

AUTO-CRUISE
CONTROL-ECU

AC002574AB

10

AC002575

11

AB

AC002576AB

12

RELAY

TSB Revision

COMPONENT LOCATIONS

70-6

RELAY

M1701000400411

NAME

SYMBOL NAME

SYMBOL

ABS relay

A

Hazard warning relay

G

A/C compressor relay

C

Headlight relay

B

Accessory socket relay

E

Horn relay

A

A/T control relay

H

Intermittent wiper relay

F

Blower relay

B

Multiport fuel injection relay

H

Condenser fan motor relay

C

Power window relay

E

Defogger relay

G

Rear heater relay

E

DRL lower relay

C

Rear intermittent wiper relay

E

DRL upper relay

C

Starter relay

B

Fuel pump relay

H

Theft-alarm horn relay

G

Fog light relay

B

Turn-signal and hazard warning flasher
unit

D

AC002556AD

A

B

D

E

F

G

H

C

AC002582

A

AB

HORN RELAY

ABS RELAY

AC002583AB

B

HEADLIGHT
RELAY

BLOWER
RELAY

STARTER RELAY

FOG LIGHT RELAY
