AUTOMATIC TRANSMISSION DIAGNOSIS TSB Revision AUTOMATIC TRANSMISSION 23A-99 STEP 6. Measure the PCM output voltage to the speed sensor. (3) Turn the ignition switch to the "ON" position. (4) Measure the voltage between terminal 73 and ground by backprobing. • The voltage should measure between 4.5 and 4.9 volts. (5) Turn the ignition switch to the "LOCK" (OFF) position. YES : Go to Step 7. AC204681AC CONNECTOR: D-134 D-134 (GR) 61 62 63 64 65 66 67 68 69 70 71 72 73 82 89 81 88 80 79 78 77 87 86 85 76 75 74 84 83 AC204918 BK D-134 HARNESS CONNECTOR : 76 85 65 72 71 73 82 75 81 74 63 64 66 70 69 68 67 78 87 79 88 89 80 77 86 62 61 83 84 |
