THIRD SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-25

THIRD SEAT ASSEMBLY

DISASSEMBLY AND ASSEMBLY

M1522003000048

ACX00632

2

3

28

27

26

24

29

4

5

44 ± 10 N·m
33 ± 7 ft-lb

44 ± 10 N·m
33 ± 7 ft-lb

33

30

4

35

36

44 ±10 N·m
33 ± 7 ft-lb

31

31

32

34

44 ± 10 N·m
33 ± 7 ft-lb

44 ± 10 N·m
33 ± 7 ft-lb

52 ± 7 N·m
38 ± 5 ft-lb

7

18 17

16

14

13

12

11

20

19

22

8

9

10

23

44 ± 10 N·m
33 ± 7 ft-lb

21

6

1

AD

15

N

25

N

THIRD SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-26

DISASSEMBLY STEPS

1.

OUTER RECLINING ADJUSTER
COVER

2.

CATCH RELEASE KNOB

3.

CATCH RELEASE KNOB
GARNISH

4.

LATCH COVER

5.

CATCH CABLE CONNECTION

6.

INNER RECLINING ADJUSTER
COVER

7.

THIRD SEATBACK ASSEMBLY

8.

RECLINING KNOB

9.

RECLINING ADJUSTER COVER

10. DAMPER
11. FOLDING LEVER KNOB
12. FOLDING KNOB GARNISH
13. THIRD SEATBACK BOARD

<<A>>

14. HEAD RESTRAINT GUIDE
15. HOG RING
16. THIRD SEATBACK FRAME
17. THIRD SEATBACK PAD

18. THIRD SEATBACK COVER
19. ROD
20. SPRING
21. RECLINING ADJUSTER
22. INNER RECLINING ADJUSTER

COVER

23. SHAFT
24. INNER SEAT BELT
25. HOG RING
26. THIRD SEAT CUSHION FRAME
27. THIRD SEAT CUSHION PAD
28. THIRD SEAT CUSHION COVER
29. CATCH CABLE
30. THIRD SEAT LATCH
31. ARM COVER
32. CAM
33. THIRD SEAT LEG FRAME
34. CATCH ASSEMBLY
35. STRIKER COVER
36. STRIKER

DISASSEMBLY STEPS

THIRD SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-27

CLAW POSITIONS

ACX00633

<OUTER RECLINING ADJUSTER COVER>

SECTION A - A

<RECLINING ADJUSTER COVER>

SECTION B - B

<FOLDING KNOB GARNISH>

SECTION C - C

<ARM COVER>

SECTION D - D

A

A

CLAW

CLAW

CLAW

CLAW

CLAW

OUTER RECLINING
ADJUSTER COVER

RECLINING
ADJUSTER

RECLINING
ADJUSTER COVER

THARD SEAT BACK
ASSEMBLY

THARD SEAT BACK
ASSEMBLY

B

B

C

D

D

D

D

C

FOLDING KNOB
GARNISH

ARM COVER

ARM COVER

AB

NOTE

:Claw position

THIRD SEAT ASSEMBLY

TSB Revision

INTERIOR

52A-28

REMOVAL SERVICE POINTS

.

<<A>>HEAD RESTRAINT GUIDE REMOVAL

ACX01300AB
