ON-VEHICLE SERVICE
TSB Revision
MULTIPORT FUEL INJECTION (MFI)
13A-987
ON-VEHICLE SERVICE
COMPONENT LOCATION
M1131002100826
NAME
SYMBOL
NAME
SYMBOL
Accelerator pedal position sensor
(with built-in accelerator pedal
position switch)
S
Left bank heated oxygen sensor (front) I
Air conditioning compressor clutch
relay
K
Left bank heated oxygen sensor (rear) V
Camshaft position sensor
G
Malfunction Indicator Lamp (SERVICE
ENGIEN SOON or check engine lamp)
R
Crankshaft position sensor
M
Manifold absolute pressure sensor
F
Data link connector
T
Multiport fuel injection (MFI) relay
J
EGR valve
D
Powertrain control module
U
Engine coolant temperature sensor
L
Power steering pressure switch
Q
Evaporative emission purge solenoid E
Right bank heated oxygen sensor
(front)
B
Evaporative emission ventilation
solenoid
X
Right bank heated oxygen sensor
(rear)
Y
Fuel level sensor
a
Throttle actuator control motor
C
Fuel pump relay
J
Throttle actuator control motor relay
J
Fuel tank differential pressure sensor a
Throttle position sensor
C
Fuel tank temperature sensor
a
Transmission range switch
Z
Ignition coil
H
Intake manifold tuning solenoid
P
Injector
O
Vehicle speed sensor
W
Intake manifold tuning solenoid
P
Volume airflow sensor (with built-in
intake air temperature sensor and
barometric pressure sensor)
A
Knock sensor
N
