SPECIFICATIONS
TSB Revision
ENGINE MECHANICAL
11A-45
SERVICE SPECIFICATIONS
M1111000300651
LUBRICANT
M1112000400059
SEALANTS
M1111000500053
Rocker arm and shaft assembly mounting bolt
31
± 3 N⋅m (23 ± 2 ft-lb)
Rocker cover attaching bolt
3.5
± 0.5 N⋅m (31 ± 4 in-lb)
Sensing camshaft position cylinder
22
± 4 N⋅m (16 ± 3 ft-lb)
Timing belt lower cover assembly attaching bolt
11
± 1 N⋅m (98 ± 8 in-lb)
Timing belt upper cover assembly attaching bolt
11
± 1 N⋅m (96 ± 8 in-lb)
Timing belt upper cover assembly attaching bolt
14
± 1 N⋅m (120 ± 13 in-lb)
Timing belt indicator bracket attaching bolt
11
± 1 N⋅m (96 ± 8 in-lb)
Tension arm assembly attaching bolt
44
± 10 N⋅m (33 ± 7 ft-lb)
Tension pulley attaching bolt
48
± 6 N⋅m (36 ± 4 ft-lb)
Transmission fluid dipstick assembly attaching bolt
44
± 8 N⋅m (33 ± 5 ft-lb)
Transmission fluid dipstick assembly attaching bolt
24
± 4 N⋅m (18 ± 3 ft-lb)
Water outlet pipe attaching bolt
14
± 1 N⋅m (120 ± 13 in-lb)
Water passage assembly attaching bolt
19
± 1 N⋅m (14 ± 1 ft-lb)
Water pipe assembly attaching bolt
14
± 1 N⋅m (120 ± 13 in-lb)
ITEMS
SPECIFICATIONS
ITEMS
STANDARD VALUE
LIMIT
Drive belt tension
Vibration frequency Hz
(Reference)
88
− 121
−
Tension N (Reference)
197
− 371
−
Basic ignition timing at idle
5
°BTDC ± 3°
−
Actual ignition timing at curb idle
Approximately 10
°
BTDC
−
CO contents %
0.5 or less
−
HC contents ppm
100 or less
−
Curb idle speed r/min
700
± 100
−
Compression pressure (250 - 400 r/min) kPa (psi)
1200 (171)
Minimum 890 (127)
Compression pressure difference of all cylinder kPa (psi)
−
100 (14)
Intake manifold vacuum at curb idle kPa (in Hg)
−
Minimum 60 (18)
Auto-tensioner pushrod movement mm (in)
Within 1.0 (0.04)
−
Timing belt tension torque N
⋅m (in-lb)
4.4 (39)
−
Auto tensioner rod protrusion amount mm (in)
4.8
− 5.5 (0.19 − 0.22)
−
ITEM
SPECIFICATION
Transmission fluid
DIAMOND ATF SP-II M or DIAMOND ATF SP III
ITEM
SPECIFIED SEALANT
Camshaft position sensor support
MITSUBISHI GENUINE Part No. MD970389 or equivalent
Oil pan
MITSUBISHI GENUINE Part No. MD970389 or equivalent
