Mitsubishi Montero (2002-2004). Manual - part 957

DIAGNOSTIC TROUBLE CODE PROCEDURES <TRANSFER>

TSB Revision

DIAGNOSTIC TROUBLE CODE PROCEDURES

23Ac-311

STEP 4. Check joint connector D-01, junction block
connector D-208, D-212, intermediate connector E-11 and
transfer shift lever switch connector E-116 for loose,
corroded or damaged terminals, or terminals pushed back
in the connector.

AC204170

CONNECTOR : D-01

CD

9 10

8

6 7

31 32

30

29

18 19 20 21

5

4

2

1

3

27

26

24

23

25

12 13 14 15 16 17

28

11
22
33

AC204191

CONNECTORS : D-208, D-212

5 6

2

4

3

1

JUNCTION BLOCK
(FRONT VIEW)

3

10

9

4

11

8

7

1

5

2

6

D-208

D-208

D-212

D-212

AS

AC204176

CONNECTOR : E-11

AZ

3

10

16

9

7 8

6

1

4

2

5

11

14

1213

15

DIAGNOSTIC TROUBLE CODE PROCEDURES <TRANSFER>

TSB Revision

DIAGNOSTIC TROUBLE CODE PROCEDURES

23Ac-312

Q: Are the connectors and terminals in good condition?

YES : Go to Step 5.
NO :  Repair or replace the damaged components. Refer to

GROUP 00E, Harness Connector Inspection

P.00E-

2

.

STEP 5. Check harness for open circuit or short circuit to
ground between junction block connector D-208 terminal 2
and transfer shift lever switch connector E-116 terminal 1.
Q: Is the harness wire in good condition?

YES : Go to Step 10.
NO :  Repair or replace the harness wire.

AC204175

CONNECTOR : E-116

AH

6

2

5

4

3

1

AC204173

CONNECTOR : D-208

BA

5 6

2

4

3

1

JUNCTION BLOCK
(FRONT VIEW)

AC204175

CONNECTOR : E-116

AH

6

2

5

4

3

1

DIAGNOSTIC TROUBLE CODE PROCEDURES <TRANSFER>

TSB Revision

DIAGNOSTIC TROUBLE CODE PROCEDURES

23Ac-313

STEP 6. Measure the switch output voltage at transfer-ECU
connector E-109 by backprobing.
(1) Disconnect connector E-109 and measure at the harness

side.

(2) Turn the ignition switch to the "ON" position.

(3) Measure the voltage between terminal 20 (Transfer shift

lever position: 2H) and ground by backprobing. [terminal 21
(Transfer shift lever position: 4H), terminal 22 (Transfer shift
lever position: 4HLc), terminal 23 (Transfer shift lever
position: 4LLc) and ground by backprobing.]

• The voltage should measure battery positive voltage.

(4) Turn the ignition switch to the "LOCK" (OFF) position.
Q: Is the measured voltage battery positive voltage?

YES : Go to Step 9.
NO :  Go to Step 7.

STEP 7. Check transfer-ECU connector E-109 and transfer
shift lever switch connector E-116 for loose, corroded or
damaged terminals, or terminals pushed back in the
connector.
Q: Are the connectors and terminals in good condition?

YES : Go to Step 8.
NO :  Repair or replace the damaged components. Refer to

GROUP 00E, Harness Connector Inspection

P.00E-

2

.

AC204176

CONNECTOR : E-109

BB

11 12

25

24

13

26

9

22

7

6

20

19

8

21

10

23

5

4

17

2

1

15

14

3

16

18

AC204918 CG

E-109 HARNESS CONNECTOR :
HARNESS SIDE

11 12

25

24

13

26

9

22

7

6

20

19

8

21

10

23

5

4

17

2

1

15

14

3

16

18

AC204176

CONNECTOR : E-109

BB

11 12

25

24

13

26

9

22

7

6

20

19

8

21

10

23

5

4

17

2

1

15

14

3

16

18

AC204175

CONNECTOR : E-116

AH

6

2

5

4

3

1

DIAGNOSTIC TROUBLE CODE PROCEDURES <TRANSFER>

TSB Revision

DIAGNOSTIC TROUBLE CODE PROCEDURES

23Ac-314

STEP 8. Check harness for open circuit or short circuit to
ground between transfer-ECU connector E-109 terminal 20
(21, 22 and 23) and transfer shift lever switch connector E-
116 terminal 3 (5, 6 and 2).
Q: Is the harness wire in good condition?

YES : Go to Step 10.
NO :  Repair or replace the harness wire.

STEP 9. Check transfer-ECU connector E-109 for loose,
corroded or damaged terminals, or terminals pushed back
in the connector.
Q: Are the connector and terminals in good condition?

YES : Go to Step 10.
NO :  Repair or replace the damaged components. Refer to

GROUP 00E, Harness Connector Inspection

P.00E-

2

.

AC204176

CONNECTOR : E-109

BB

11 12

25

24

13

26

9

22

7

6

20

19

8

21

10

23

5

4

17

2

1

15

14

3

16

18

AC204175

CONNECTOR : E-116

AH

6

2

5

4

3

1

AC204176

CONNECTOR : E-109

BB

11 12

25

24

13

26

9

22

7

6

20

19

8

21

10

23

5

4

17

2

1

15

14

3

16

18
