Mitsubishi Montero (2002-2004). Manual - part 510





RV METER

TSB Revision

CHASSIS ELECTRICAL

54A-211

.

CIRCUIT OPERATION
The RV meter calculates the drive range, based on
the residual fuel quantity signal from the fuel level
sensor, receiving the fuel injection quantity data from
the power train control module.

.

TECHNICAL DESCRIPTION (COMMENT)
When the abnormal vibration of fuel gage pointer in
the combination meter is found, the fuel level sensor
is considered to be failed.

.

TROUBLESHOOTING HINTS

• Malfunction of the fuel level sensor

• Damaged harness wires and connectors

.

DIAGNOSIS

Required Special Tool:

• MB991223: Harness Set

STEP 1. Check the powertrain control module.
Q: Is the diagnostic trouble code of the power train control

module output?
YES :
Carry out troubleshooting of the powertrain control

modul

P.13Ab-22

.

NO :  Go to Step 2.

AC204176

CONNECTOR: E-111

AK

AC204178

CONNECTOR : F-07

AO

F-07(B)

AC204179

CONNECTOR : G-03

BB

G-03(B)

RV METER

TSB Revision

CHASSIS ELECTRICAL

54A-212

STEP 2. Check the RV meter connector D-08 and
powertrain control module connector D-134 for loose,
corroded or damaged terminals, or terminals pushed back
in the connector.
Q: Are RV meter connector D-08 and powertrain control

module connector D-134 in good condition?
YES :
Go to Step 3.
NO :  Repair or replace it. Refer to GROUP 00E, Harness

Connector Inspection

P.00E-2

.

AC204170

CONNECTOR : D-08

AE

D-08(B)

HARNESS
SIDE

D-08(B)

1

3

4

2

12

1413

11

6

7

8

10 9

18

19

20

16

17

5

15

AC204171

CONNECTOR : D-134

D-134(GR)

D-134(GR)

AT

HARNESS SIDE

80

87

73

66

67

65
74

81

75

82

6261

72

68

69

70

71

78

85

77

8483

76

79

86

63

64

8988

RV METER

TSB Revision

CHASSIS ELECTRICAL

54A-213

STEP 3. Check the harness wires between RV meter
connector D-08 (terminal 15) and powertrain control
module connector D-134 (terminal 74).

NOTE: After inspecting intermediate connector E-111 inspect
the wires. If intermediate connector E-111 is damaged, repair or
replace it. Refer to GROUP 00E, Harness Connector Inspec-
tion

P.00E-2

.

Q: Are the harness wires between RV meter connector D-

08 (terminal 15) and powertrain control module
connector D-134 (terminal 74) in good condition?
YES :
Go to Step 4.
NO :  Repair or replace it. Refer to GROUP 00E, Harness

Connector Inspection

P.00E-2

.

AC204170

CONNECTOR : D-08

AE

D-08(B)

HARNESS
SIDE

D-08(B)

1

3

4

2

12

1413

11

6

7

8

10 9

18

19

20

16

17

5

15

AC204171

CONNECTOR : D-134

D-134(GR)

D-134(GR)

AT

HARNESS SIDE

80

87

73

66

67

65
74

81

75

82

6261

72

68

69

70

71

78

85

77

8483

76

79

86

63

64

8988

AC204176

CONNECTOR : E-111

BF

15

4

14

37

36

26 27

12

11

35

34

23 24

3

13

25

9

2

8

32

20 21

6

5

17

29

30

18

1

7

19

31

10

22

33

16

28

38

RV METER

TSB Revision

CHASSIS ELECTRICAL

54A-214

STEP 4. Check the RV meter connected D-07 and fuel level
sensor connector G-03 for loose, corroded or damaged
terminals, or terminals pushed back in the connector.
Q: Is the RV meter connected D-07 and fuel level sensor

connector G-03 in good condition?
YES :
Go to Step 5.
NO :  Repair or replace it. Refer to GROUP 00E, Harness

Connector Inspection

P.00E-2

.

AC204170

CONNECTOR : D-07

CT

HARNESS SIDE

D-07(B)

D-07(B)

22

23

30

31

25

26

33

34

32

24

28

3635

27

29

21

AC204179

CONNECTOR : G-03

AU

G-03(B)

G-03(B)

HARNESS
SIDE

2

3

1
