RV METER

TSB Revision

CHASSIS ELECTRICAL

54A-203

STEP 4. Check the RV meter power supply circuit (battery)
at the RV meter connector D-07 by backprobing.
(1) Do not disconnect the RV meter connector D-07.

(2) Measure the voltage between terminal 26 and ground by

backprobing.

Q: Is the voltage approximately 12 volts (battery positive

voltage)?
YES : Go to Step 7.
NO :  Go to Step 5.

STEP 5. Check RV meter connector D-07 for loose,
corroded or damaged terminals, or terminals pushed back
in the connector.
Q: Is RV meter connector D-07 in good condition?

YES : Go to Step 6.
NO :  Repair or replace it. Refer to GROUP 00E, Harness

Connector Inspection

P.00E-2

. The RV meter should

work normally.

AC204170

CONNECTOR : D-07

CT

HARNESS SIDE

D-07(B)

D-07(B)

22

23

30

31

25

26

33

34

32

24

28

3635

27

29

21

AC204738

28

26

34

27

35

25

33

23 24

32

36

22

30

21

29

31

AC204738 DU

HARNESS SIDE: D-07

AC204170

CONNECTOR : D-07

CT

HARNESS SIDE

D-07(B)

D-07(B)

22

23

30

31

25

26

33

34

32

24

28

3635

27

29

21

RV METER

TSB Revision

CHASSIS ELECTRICAL

54A-204

STEP 6. Check the harness wires between D-07 (terminal
26) and battery.
NOTE: Also check joint connector D-02 and intermediate con-
nector D-28, check the wires. If joint connector D-02 and inter-
mediate connector D-28 are damaged, repair or replace them.
Refer to GROUP 00E, Harness Connector Inspection

P.00E-2

.

Q: Is the harness wires between D-07 (terminal 26) and

battery in good condition?
YES : There is no action to be taken.
NO :  Repair them. The RV meter should work normally.

STEP 7. Check the RV meter power supply circuit [ignition
switch (ACC)] at the RV meter connector D-07 by
backprobing.
(1) Do not disconnect the RV meter connector D-07.
(2) Turn the ignition switch to "ACC" position.

(3) Measure the voltage between terminal 25 and ground by

backprobing.

Q: Is the voltage approximately 12 volts (battery positive

voltage)?
YES : The RV meter should work.
NO :  Go to Step 8.

AC204188

CONNECTORS: D-02, D-07, D-28

BR

D-28

D-28

D-02

2 3

27

32

28

33

16

15

4 5

19

18

29

17

34

7 8

35

22

21

9 10

30

36

31

37

25

24

23

6

20

1

14

26

11

13

12

38

HARNESS SIDE

D-07(B)

D-07(B)

22

23

30

31

25

26

33

34

32

24

28

3635

27

29

21

9 10

8

6 7

31 32

30

29

18 19 20 21

5

4

2

1

3

27

26

24

23

25

12 13 14 15 16 17

28

11
22
33

HARNESS SIDE

D-02

AC204170

CONNECTOR : D-07

CT

HARNESS SIDE

D-07(B)

D-07(B)

22

23

30

31

25

26

33

34

32

24

28

3635

27

29

21

AC204738 DT

HARNESS SIDE: D-07

28

26

34

27

35

25

33

23 24

32

36

22

30

21

29

31

RV METER

TSB Revision

CHASSIS ELECTRICAL

54A-205

STEP 8. Check RV meter connector D-07 for loose,
corroded or damaged terminals, or terminals pushed back
in the connector.
Q: Is RV meter connector D-07 in good condition?

YES : Go to Step 9.
NO :  Repair or replace it. Refer to GROUP 00E, Harness

Connector Inspection

P.00E-2

. The RV meter should

work normally.

AC204170

CONNECTOR : D-07

CT

HARNESS SIDE

D-07(B)

D-07(B)

22

23

30

31

25

26

33

34

32

24

28

3635

27

29

21

RV METER

TSB Revision

CHASSIS ELECTRICAL

54A-206

STEP 9. Check the harness wires between D-07 (terminal
25) and ignition switch (ACC).

NOTE: Also check joint connector D-29 and junction block con-
nector D-208 and D-210, check the wires. If joint connector D-
29 and junction block connector D-208 and D-210 are dam-
aged, repair or replace them. Refer to GROUP 00E, Harness
Connector Inspection

P.00E-2

.

Q: Is the harness wires between D-07 (terminal 25) and

ignition switch (ACC) in good condition?
YES : There is no action to be taken.
NO :  Repair them. The RV meter should work normally.

AC204188

CONNECTORS: D-07, D-29

D-29

BS

D-29

9 10

8

6 7

31 32

30

29

18 19 20 21

5

4

2

1

3

27

26

24

23

25

12 13 14 15 16 17

28

11
22
33

HARNESS SIDE

HARNESS SIDE

D-07(B)

D-07(B)

22

23

30

31

25

26

33

34

32

24

28

3635

27

29

21

AC204191

CONNECTORS: D-208, D-210

D-208

AC

HARNESS SIDE

HARNESS SIDE

D-210

D-208

D-210

1

2

3

5

6

4

1

2

7 6

3

9

4

11

12

10

13

5

8
