STARTING SYSTEM TSB Revision ENGINE ELECTRICAL 16-21 INSPECTION M1162001100023 . PINION GAP ADJUSTMENT magnetic switch. 2. Connect a 12-volt battery between the S-terminal and M- terminal. CAUTION This test must be performed quickly (in less than 10 sec- 4. Check the pinion-to-stopper clearance (pinion gap) with a feeler gauge. Standard value: 0.5 − 2.0 mm (0.02 − 0.07 inch) 5. If the pinion gap is out of specification, adjust by adding or removing gasket(s) between the magnetic switch and front . MAGNETIC SWITCH PULL-IN TEST magnetic switch. CAUTION This test must be performed quickly (in less than 10 sec- terminal. 3. If the pinion moves out, the pull-in coil is good. If it doesn't, replace the magnetic switch. . AKX00197 SWITCH S B M WIRE STARTER BATTERY AB AKX00198 STOPPER PINION GAP PINION AB AKX00199 AKX00200 S B M WIRE STARTER BATTERY AB |
